Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Printed Electrolytic Tinplate ETP Steel Coil For Packaging
Specifications
Brand Name :
TOBO
Place of Origin :
CHINA
MOQ :
25ton
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
300ton/month
Delivery Time :
10-15workdays
Packaging Details :
Wooden tray, iron wrapper, waterproof paper.
Standard: :
AiSi, ASTM, bs, DIN, GB, JIS
Grade: :
tinplate
Width: :
600-1500MM
Thickness: :
1.14-6.0MM
Hardness: :
T1-T5
Model Number: :
T1,T2,T2,T4,T5,T6,T7
Application: :
t1
Tolerance: :
±1%
Processing Service: :
Bending, Welding, Decoiling, Punching, Cutting
Tin coating: :
1.1-5.6
Coil Weight: :
3-10Tons
Delivery Time: :
Within 25-30days
ID: :
508mm or 610mm
MOQ: :
25 Ton
Description

Printed Electrolytic Tinplate ETP Steel Coil For Packaging

STANDARD
GB, JIS, DIN ,ASTM
MATERIAL
MR SPCC
Grade
Prime
Annealing
BA CA
SIZE
Thickness:0.14-6.0mm
width :600-1500mm
TEMPER
T1,T2,T3,T4,T5,DR7;DR8;DR9;TH550;
TH580;TH620;TH660
COATING
1.1/1.1 2.0/2.0 2.8/2.8 2.8/5.6
5.6/5.6 8.4/8.4 11.2/11.2 g/m2
TFS coating
80-100 g/m2
FINISH
Stone,Bright,Silver
PACKING
Standard export packing.
or according to customer's requirements.
PAYMENT
T/T or L/C or D/P
WEIGHT
6--25ton/coil
Oiling
DOS

Product Introduction

Tinplate(SPTE) is a common name for electroplated tin steel sheets, which refers to cold-rolled low-carbon steel sheets or strips coated with commercial pure tin on both sides. Tin mainly acts to prevent corrosion and rust. It combines the strength and formability of steel with the corrosion resistance, solderability and aesthetic appearance of tin in a material with corrosion resistance, non-toxicity, high strength and good ductility.Tin-plate packaging has a wide range of coverage in the packaging industry because of its good sealing, preservation, light-proof, ruggedness and unique metal decoration charm. Because of its strong antioxidant, diverse styles and exquisite printing, tinplate packaging container is popular with customers, and widely used in food packaging, pharmaceutical packaging, commodity packaging, instrument packaging, industrial packaging and so on.
Coating Structure
Mechanical Properties
emper Grade
Hardness(HR30Tm)
Yield Strength(MPa)
T-1
49±3
330
T-2
53±3
350
T-3
57±3
370
T-4
61±3
415
T-5
65±3
450
T-6
70±3
530
DR-7M
71±5
520
DR-8
73±5
550
DR-8M
73±5
580
DR-9
76±5
620
DR-9M
77±5
660
DR-10
80±5
690
Coating Weight
Former Coating Designation
Nominal Coating Weight(g/m2)
Minimum average Coating Weight (g/m2)
10#
1.1/1.1
0.9/0.9
20#
2.2/2.2
1.8/1.8
25#
2.8/2.8
2.5/2.5
50#
5.6/5.6
5.2/5.2
75#
8.4/8.4
7.8/7.8
100#
11.2/11.2
10.1/10.1
25#/10#
2.8/1.1
2.5/0.9
50#/10#
5.6/1.1
5.2/0.9
75#/25#
5.6/2.8
5.2/2.5
75#/50#
8.4/2.8
7.8/2.5
75#/50#
8.4/5.6
7.8/5.2
100#/25#
11.2/2.8
10.1/2.5
100#/50#
11.2/5.6
10.1/5.2
100#/75#
11.2/8.4
10.1/7.8
125#/50#
15.1/5.6
13.9/5.2
Production Process
Printed Electrolytic Tinplate ETP Steel Coil For PackagingPrinted Electrolytic Tinplate ETP Steel Coil For PackagingPrinted Electrolytic Tinplate ETP Steel Coil For Packaging

Our Advantages

WHY CHOOSE US

TEAM

More than 120 top-class mills

EQUIPMENT

A number of advanced equipments

QUALITY

Company with a variety of detection devices

FACTORY

We have five branch factories

If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.

If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term cooperated agent also available.

FAQ

FAQ

1. Are you trading company or manufacturer ?

We are manufacturer ,You can see the Alibaba certification.

2. How long is your delivery time?

Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

3. Do you provide samples ? is it free or extra ?

Yes, we could offer the sample for free charge but need pay the cost of freight.

4. What is your terms of payment ?

Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.

Packaging&Shipping

Package:Standard export carton packing.

Delivery time:stock-45 days after confirming order,detail delivery date should be decided according to production season and order quantity.
