Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Monel K500 Stainless Steel Seamless Pipe 3 Elbow 90LR Heavy Machining OEM
Specifications
Brand Name :
TOBO/TPCO/TISCO/VALIN/METAL
Model Number :
Monel K500 UNS N05500
Certification :
ISO/PED/TUV/SGS/LR/BV
Place of Origin :
China/Japan/Germany
MOQ :
300 Kilogram/Kilograms
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 Metric Ton/Metric Tons per Month
Delivery Time :
7-30 working days after received deposit
Packaging Details :
Export standards or customer requirements
Product Name :
Elbow
Product Type :
steel pipe
Grade :
200 Series &300 Series &400 Series
Shape :
Round
OD :
168.3 - 3048 mm
Surface :
painted
Application :
Oil Pipe
Techinque :
Cold Drawn
Description

Alloy Steel Monel K500 UNS N05500NACE MR0175 3'' Elbow 90LR STD Pipe Fittings

Monel K-500 is readily fabricated by standard commercial procedures.
Welding alloy K-500 is best accomplished by the gas-tungsten-arc welding process. It is recommended that Monel K-500 be annealed when it is welded and that any weldments be stress relieved prior to aging.
Heavy machining of this alloy is best accomplished when the material is in the annealed condition or hot-worked and quenched condition. Age-hardened material however can be finish-machined to close tolerances and fine finishes. Therefore, the recommended practice is to machine slightly oversize, age-harden, then finish to size. During aging, a slight permanent contraction takes place, but little warpage occurs because of the low temperatures and slow cooling rates involved.

Specifications

BarRod
AMS 4676AMS 4676

Mechanical Properties

Typical Room Temperature Tensile Properties of Annealed Material

Product FormConditionTensile (ksi).2% Yield (ksi)Elongation %Hardness
Rod & BarHot-Finished/Aged140-190100-15030-2027-38 HRC
Rod & BarHot Finished/Annealed90-11040-6045-2575-90 HRB
Rod & BarHot Finished/Annealed/Aged130-16585-12035-2024-35 HRC
Rod & BarCold-Drawn/Aged135-18595-16030-1525-41 HRC
Rod & BarCold-Drawn/Annealed/Aged130-19085-12030-2024-35 HRC
Plateot-Finished/Aged140-180100-13530-2027-37 HRC
SheetCold-Rolled/Annealed90-10540-6545-2585 HRB Max

Product Specification
Namepipe fitting elbow
Materialstainless steelASTM A240 304 304L 316L 321 321H 347 347H 904L ASTM A789 S31803 S32205 S32750
Carbon SteelASTM A234 WPB A420 WPL3 WPL6 A516 GR70 GR65 GR60 GR55 ISO3183/API 5L L36/X52 L415/X60 L450/X65 L485/X70?
Alloy SteelASTM A335 P11 P22 SA387 GR.11 GR.22
TitaniumGr1 Gr2 Gr3 Gr5 Gr7 Gr12
Copper/BrassWe can also produce according to customer's requirements
Standard??ASME B16.9, ANSI B16.9, ASTM , JISB2312,DIN,BS, GBT12459-05, GB13401-05,GOST
ASME B16.9-2007,MSS SP 43-1991,MSS SP-75,ASTM B363
Wall thickness

Sch5S, Sch10S, Sch40S, Sch80S
Sch10,Sch20,Sch30,STD,Sch40,Sch60,XS,Sch80,Sch100,Sch120,Sch140,Sch160,XXS,

Size1/2"-96" ? DN15-DN2400
TypeButt welded or Seamless
ShapeEqual or Reducing
Product

1.Elbow?L/R & S/R (45/90/180 DEG)
according to customer's requirement can produce the other's degree, such as 22.5 degree 30 degree 60 degree etc.

2. Tee(Straight and Reducing)
3. Reducer(Concentric and Eccentric)
4. Cross
5. Cap(Round and Elliptical)
6. Stub End
Quality ControlGood quality control system which covers every process of the manufacturing-Raw material inspection,cutting,bending,sizing,shot blasting,beveling,coating,marking,packing,delivery;
ApplicationPipe fitting is the occupation of installing or repairing piping or tubing systems that convey liquid, gas, and occasionally solid materials. This work involves selecting and preparing pipe or tubing, joining it together by various means, and the location and repair of leaks.
SurfaceBlack painting ; Pickling ; Sand blasting
CertificateISO9001 ; ISO9001:2008
PackageWood case or Wooden pallets or according to the customer's requirements.
Features

1) Chemical and Physical characteristic: durable, corrosion resistant and high-temperature resistant
2) We also produce pipes with special specifications according to customers' requirements;

Lead TimeWithin 30 days or according to the customer's requirements.
MOQ1 Piece
OEMYES

Monel K500 Stainless Steel Seamless Pipe 3Monel K500 Stainless Steel Seamless Pipe 3
