BW-VG220 Low-Cost MEMS Voltage Dynamic Inclinometer 0-5V/0-10V Optional

Introduction:

VG200 can measure inertial attitude parameters such as rolling and pitching of moving carrier, angular velocity and acceleration. It is a low-cost attitude measurement equipment. It adopts MEMS accelerometer and gyroscope with high quality and reliability, and ensures the measurement accuracy through algorithm. At the same time, the sealing design and strict technology ensure that the product can still accurately measure the carrier attitude parameters in harsh environment. Vg200 has digital interface, which can be easily integrated into the user's system.

Performance Index:

Application:

● Construction Machinery

● Platform stability

● Agricultural machinery

● ROV underwater robot navigation

● Unmanned Drive

BWSENSING's Accuracy Traceability System:

Company introduction

Wuxi Bewis Sensing Technology LLC(BWSENSING) is an innovative fast growing company established in 2010. The company was born in The Institute of Microelectronics (IME) of Peking University. We have achieved the top spot in the middle and high-end industry applications in the Chinese market.

From 2019, BWSENSING ® is approved as our global brand.With 10 years experience in the research-design-development and manufacture of a range of Inertial sensor technology, BWSENSING posses the skills, knowledge and experience to provide fully integrated OEM/ODM design and manufacturing services for Inclinometer, Electronic Compass, IMU, AHRS, GNSS/INS and Fiber Optic Gyroscope. As the company co-founder Dr. Guangyi Shi said, we will use the Accurate and Cost-effective sensors to make a greater contribution to the global society for a better IoT world.

FAQ

Q1: Accuracy definition of products

A: RMS accuracy, the accuracy of each product can be traced.Accuracy test report can be provided if required.

Q2: How to select suitable model?

A: Users should check the following points:

a. Single or dual axis?

b. Commom protocol, Modbus or CAN?

c. Dynamic or static Application scenarios?

d. Horizontal or vertical installation?

Q3: How to purchase?

A: If you want sample, please purchase on BWSENSING online shop. We accept Paypal/TT/CC.If you purchase in bulk, it is recommended to consult the sales for the best price.

Q4: How long is the warranty period?

A: One year.

Q5: Can analog quantity change the range?

A: User-defined settings can be made on the Beiwei host computer with RS232-USB through the reserved RS232 wire harness.
