Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool
Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool
Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool
Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool
Specifications
Brand Name :
BWIN
Model Number :
CCMT060208
Place of Origin :
China
MOQ :
10pcs/box
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1-10000pcs 7days
Delivery Time :
7 work days
Packaging Details :
Plastic box
Product name :
Machining CCMT Cutting Tool
Material :
CCMT Tungsten Carbide Inserts
Workpiece :
Steel/Cast iron/Stainless steel
Usage :
CNC Cutting
Color :
Fuchsia/Yellow/Brown/Black
Coating :
PVD CVD
Hardness :
HRC40-HRC60
Feature :
Good heat resistance
Application :
Turning
Package :
10pcs/Box
Description

Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool

CCMT1204 Tungsten Carbide Inserts Machining CCMT 060208 PM Cutting Tool

Quick Detail

  • High hardness
  • Strong compression force
  • Antioxidant
  • Collapse resistance and wear resistance
  • Stable processing

Description

The CCMT cnc carbide inserts pressed with original powder, with good cutting edge, high cutting strength, firmness and wear resistance, improving efficiency and extending processing service life; The carbide with special crystal structure makes the blade have high hardness, good toughness and high temperature resistance, and makes the anti-wear performance of the blade back face stronger; Nano coating, the blade has smooth chip removal, higher hardness, sharp edge, high smoothness, good toughness, durable wear resistance, and economic efficiency; The blade is sharp, the four corners are available, the chip breaking and chip removal are smooth, and the processing efficiency is improved.

Specifications:

Brand BWIN
Model KNUX160405L KNUX160405R
Color Fuchsia/Yellow/Brown/Black
Workpiece Steel/Cast iron/Stainless steel
Type CNC Carbide Lathe Insert
Material Tungsten Carbide Lathe Insert
Processing Type Medium Cutting
Feature High hardness
Strong compression force
Antioxidant
Collapse resistance and wear resistance

Stable processing
Standard ISO
Quantity 10pcs/box
Weight 0.015kg
Package Plastic Box
Customized Support OEM, ODM

Lead Time

antity(pieces) 1 - 3000 >3000
Lead time (days) 7 To be negotiated

Notice

  • The cnc carbide insert shall not be collided or dropped on the ground and must be handled with care.
  • Before installing the tungsten carbide lathe insert, the performance and purpose of the saw table must be confirmed to ensure that the cutting direction indicated by the blade arrow is consistent with the rotation direction of the saw table. It is strictly prohibited to install in the opposite direction. Wrong installation direction may cause the blade sawtooth to fall off, so as to prevent accidents.
  • After installation, it is necessary to confirm whether the central hole of the carbide lathe insert is firmly fixed on the flange plate of the saw table. If there is a gasket, the gasket must be sleeved; Then, gently push with your hand to confirm whether the blade rotates eccentrically.
  • When using, do not exceed the specified high speed
  • When the cnc carbide insert is not used, hang the blade vertically on the dry shelf.

Applications:

Our cnc carbide insert could to be processed Alloy steel, Tool steel, carbon steel, stainless steel, Cast iron and Titanium alloy. Working material as following:

Tungsten Carbide CCMT060208 CNC Turning Inserts PM Cutting Tool

Advantages

  • Imported raw powder materials,
  • Have a peculiar gradient cobalt-rich on surface of the substrates which can ensure the inserts’ high performance when finishing the CVD coating.
  • The coating materials are MT-TiCN0-Al2O3 with thickness of 14μm, which have high abrasion resistance. After special management on the surface of the coating inserts, the internal stress and surface of coating were reduced while cutting resistance was also cut down.
  • Our BPS series grade can cutting steel and alloy steel from finish machining, to semi-finish and rough machining.
FAQ

1. Flank Wear?

Higher cutting resistance,Notch wear on flank,Poor roughness of surface, or deterioration of accuracy.

Soft grades,Excessive cutting speed,Small flank angle,Low feed.
Select a higher,wear-resistant grade,Reduce cutting speed,Increase flank angle,Increase feed.
2. Crater Wear?
Uncontrolled chip,Poor surface quality,when finishing High speed processing carbon steel
Soft grades,Excessive cutting speed,Excessive feed,The strength of chip breaker Insufficiet.
Change to a higher wear-resistant grade,Reduce cutting speed,Reduce feed,Select a higher strength chip breaker.
3. Chipping?
Sudden fracture of cutting edge(rake face and flank),Instability insert life
Toughness insufficient,Excessive feed rate,Strength of cutting edge insufficient,Instability of the tool.
Select a tougher grade,Decrease feed rate,Increase honing of cutting edge(chamfering to rounding),Increase the stability and setting angle
4. Insert Fracture?
Cutting resistance increased Poor surface roughness.
Toughness insufficient,Excessive feed rate,Strength of cutting edge insufficient,Instability of the tool.
Select a tougher grade,Decrease feed rate,Increase honing of cutting edge(chamfering to rounding),Increase the stability and setting angle.
5. Plastic Deformation?
Variation of dimension Nose wear,cutting edge drape or passivating.when processing alloy steel Poor surface roughness
Soft grade,Excessive cutting speed,Excessive cutting depth and feed rate,Overheat on cutting edge.
Select a higher red hardness cutting material,Decrease cutting speed,Decrease cutting depth and feed rate,Select a higher thermal conductivity cutting material(CVD+sufficient coolant).
6. Build-Up-Edge?
Workpiece dissove with Cutting edge Poor surface roughness when finishing,Cutting resistance increased,Cutting soft materials.
Cutting speed too low,Cutting edge obtuse,Unsuitable tool material. Increase cutting speed,Increase rake angle,Select small sticking force.
