ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
Specifications
Certification :
CE UL ROHS
Place of Origin :
China
Brand Name :
MARSHINE
MOQ :
1PC
Packaging Details :
Wooden Box, Wooden Pallet
Delivery Time :
15-30DAY
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
200 CONTAINER/YEAR
Model Number :
SCHX-25
Price :
usd, 180-310, pcs
Maximum Compression (Kn) :
250-2000 kn
Maximum Oil Pressure (MPa) :
70-94 Mpa
Stroke (mm) :
25-35 mm
Weight (Kg) :
5.5-85 kg
Product Type :
Double Column Hydraulic Press
Transport Package :
Industry Packing or Can be customized
Brand of the product :
MARSHINE
Place of the Origin :
China
HS Code :
8467890000
Product Feature :
Automation , Precision , High Efficiency
Product Name :
Hydraulic Wire Crimping Tool
Condition :
Brand New
Description
High Pressure Hydraulic Cable Crimping Compressor Tool for ACSR Conductor

This MARSHINE High Pressure Hydraulic Cable Crimping Compressor Tool for ACSR Conductor is capable of crimping conductors, ground wires, and terminals that connect aluminum wires to copper wires. Our products can be divided into various types. Models 16101 and 16102 are equipped with manual or single-tube electric pumps. Models 16103, 16104, and 16105 are equipped with ultra-high pressure hydraulic pump stations. In addition, matching dies need to be purchased separately.
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper

Technical Parameters

Item number Model Maximum Compression(kN) Maximum oil pressure (MPa) Suitable copper terminals Stroke(mm) Weight (kg)
16101 SCHX-25 250 70 50-630 5.5
16101A FYQ-630A 316 70 150-630 35 15.4
16101B SCHX-45 450 70 50-800 10.6
16102 QY-35 350 70 25 12
16103 QY-65 650 94 ≤ACSR500 25 25
16104 QY-125 1250 94 ≤ACSR720 25 40
16105 QY-200 2000 94 ≤ACSR1440 25 85
To support the Transmission work, Marshine Power has Gin Pole Hardware, Cable Compression Cutting Machine, Cable Stringing Equipments,Cable Drum Trailer, Cable Gripper, Miscellaneous Tools- all are OEM and professionally produced per ISO 9001:2008, which are being sold to over more than 50 countries in the world. Some items like emergency restoration tower and crossing structure, we can customized, and the safety tools and accessories, are not demanded the MOQ. You can freely help you out either Tech issue or Products requirements. Pls approach us. Thanks.
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper
ACSR Conductor Double Column Hydraulic Press High Pressure Cable Crimper

1.Training and services.
Marshine is a company specializing in the development, designand manufacture of electrical construction equipment and tools.
We not only produce but also sell international standard products,OEM and custom products,and provide quality tracking and service monitoring.

2. How about the quality of your products?
Our products are manufactured in strict accordance with domistic and international standards, and each product is tested before delivery. If you would like to view our quality certification and various test reports, please consult us.

3. Why do you choose us?
Because we can provide you with excellent service, high quality products and reasonable price. In addition, we can also provide smooth delivery of goods, excellent customer solutions.

4. Customer inquiry.
If there is an emergency, customers can also use ononline Chat methods (Skype, wechat) for faster and better communication. Any enquiry will be answered within 12 working hours.

5. How to obtain samples?
We can provide free samples to the buyer for testing, but the buyer needs to pay the freight. Existing samples take 2-3 days. If there is no stock, we will advise the delivery date.

6. How about packing and shipping?
All goods will be packed in plywood boxes for safe, long haul transport. Support EXW, FOB, CIF, CFR terms.
Required documents such as packing list, commercial invoice, bill of lading, air waybill, CO, Form E, Form F etc will be provided.

Note: If you dom't find the product you need, please feel free to contact us. We will provide the best quotation as soon as we verify your requirements.
