UL ISO Bell Mouth Tubular Copper Tube Lug For Car Wire Connecting
UL ISO Bell Mouth Tubular Copper Tube Lug For Car Wire Connecting
UL ISO Bell Mouth Tubular Copper Tube Lug For Car Wire Connecting
UL ISO Bell Mouth Tubular Copper Tube Lug For Car Wire Connecting
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
YL
Model Number :
BC 1.5~630sqmm
Supply Ability :
20 Ton/Tons per Day
Packaging Details :
30pcs / transparent poly bags,15bags/ carton , carton size27.5*19*25cm/ pallet end
MOQ :
2000 Piece/Pieces
Price :
$0.01 - $0.10/ Piece
Type :
Crimp Terminal
Material :
Pure Copper
Certificate :
UL, Rosh, Reach, ISO
Surface treatment :
Coated Tin
Application :
Wire Connecting
Special :
OEM Service Offered
Color :
Silver
Name :
China High quality cable lug price
Description

UL ISO Bell Mouth Tubular Copper Cable Terminal For Car

Product Description

China High quality bell mouth cable lug price

professional manufacturer of copper lugs and terminals in China for more than 20 years, products have been exported to more thna 50 coutries and regions.
Material: High Conductivity Copper
Purity: >99.9%
Coating: Shinning Tin

Patent cable lug, China Brand name,Taiwanese mature technology, Top quality for long life time

1. Material: 100% Pure copper,Top material to producing out good quality products
2. Size: 1.5mm2~630mm2
3. Standard: JIS/DIN/Singapore/UK
4. Certification: UL, ISO9001, ROHS, Reach

Product Name China High quality cable lug price
Material Pure copper
Color Silver
Standard JIS/DIN/Singapore/UK
Certification UL, Rosh, Reach, ISO9001
Used Car, ship, telecommunication equipment, controller systerm, power cabinet

UL ISO Bell Mouth Tubular Copper Tube Lug For Car Wire Connecting

PART NO TYPE A B W E D L C
03601 1.5-3 3.3 1.8 6.5 3.0 5.5 16.0 3.3
03602 1.5-4 4.5 17.0 4.4
03603 1.5-5 7.5 19.0 5.3
03604 2.5-3 4.2 2.3 7.5 5.0 6.0 16.0 3.3
03605 2.5-4 18.0 4.4
03606 2.5-5 8.5 19.0 5.3
03607 2.5-6 9.0 6.0 6.4
03607 4-4 5.0 3.0 8.5 6.0 6.5 21.0 4.4
03608 4-5 9.0 6.0 22.0 5.3
03609 4-6 10.0 7.0 23.0 6.4
03610 6-5 6.0 4.0 9.5 6.0 6.5 22.0 5.3
03611 6-6 10.0 7.0 23.0 6.4
03612 6-8 13.6 10.0 30.0 8.4
03613 10-5 6.9 4.4 10.5 5.9 9.0 27.0 5.4
03614 10-6 6.4
03615 10-8 14.0 9.7 10.0 35.0 8.4
03616 10-10 16.0 12.0 39.0 10.5
03617 10-12 18.0 12.5
03618 16-5 8.0 5.6 11.0 5.9 11.0 29.5 5.4
03619 16-6 6.4
03620 16-8 14.0 9.7 38.0 8.4
03621 16-10 16.0 12.0 42.0 10.5
03622 16-12 18.0 12.5
03623 25-5 9.5 7.0 13.5 9.7 10.0 40 5.4
03624 25-6 6.4
03625 25-8 8.4
03626 25-10 16.8 12.0 43.5 10.5
03627 25-12 18.0 12.7
03628 35-5 11.0 8.2 15.5 9.7 14.0 41.0 5.4
03629 35-6 6.4
03630 35-8 8.5
03631 35-10 12.0 45.0 10.5
03632 35-12 18.0 13.0
03633 35-14 20.0 15.0 50.0 14.7

FAQ

Q1: Are you trading company or manufacturer ?

A: We are directly factory, there is not any trading company between us, help you save much cost

Q2: How can you proof of pure copper?

1: we provide free sample to test

2: we provide third party material analasys report for your check

3: Your are allowed to arrange third party to inspect us freely

Q3: How long is your delivery time?

A: Generally it is 5 working days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q4: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q5: What is your terms of payment ?

A: T/T for large order and western union for sample order
