24A 6.6sqmm Fully Electrical Wire Terminals ISO14001 For Electricity Equipment
24A 6.6sqmm Fully Electrical Wire Terminals ISO14001 For Electricity Equipment
Specifications
Brand Name :
YL
Model Number :
OEM
Place of Origin :
Jiangsu, China
MOQ :
200000 Piece/Pieces
Price :
$1.00 - $1.10 / Piece
Supply Ability :
20 Ton/Tons per Day
Packaging Details :
1000PCS/transparent poly bag,15bags/carton ,carton size 30*22.5*20cm
Type :
Crimp Terminal
Material :
Pure Copper
Certificate :
UL
Application :
Wire Connecting
Surface treatment :
Coated Tin
Special :
OEM Service Offered
Usage :
Electricity Equipment
Port :
Shanghai port
Description

24A 6.6sqmm Fully Insulated Terminals ISO14001 For Electricity Equipment

Fully Insulated Heat Shrinkable Female Disconnectors are electro-tin plated for excellent conductivity and resistance to corrosion. They have a maximum temperature of 105˚C with 300 volts maximum electrical rating.

These crimp terminals are waterproof and have a maximum heat shrinkable temperature of 150˚C.

Specification:

24A 6.6sqmm Fully Electrical Wire Terminals ISO14001 For Electricity Equipment

PART
NO		 TYPE WIRE RANGE B W L φd φD G H Max current
A		 Crimping tools
AWG/MCM mm²
01701 RF110(5)F 22-16 0.5-1.6 3.9 5.8 20.2 2.1 3.7 5.1 11.5 10 YYT-1
YYT-7
01702 RF110(8)F
01703 RF187(5)F 5.8 7.8 21.5 1.9 6.0
01704 RF187(8)F
01705 RF250F 7.6 9.2 23.5 6.4 10
01716 RF250F-D 24.5 4.8 11.5
01706 BF110(5)F 16-14 1.0-2.6 3.9 5.8 20.0 2.3 4.3 5.1 10 15
01707 BF110(8)F
01708 BF187(5)F 5.8 7.8 22.5 5.0 6.4
01709 BF187(8)F
01710 BF250F 7.6 9.6 23.5
01717 BF250F-D 24.5 4.5
01711 YF110(5)F 12-10 2.6-6.6 3.9 5.8 20.0 3.5 5.4 6.4 11 24
01712 YF110(8)F
01713 YF187(5)F 5.8 7.8 21.5
01714 YF187(8)F
01715 YF250F 7.6 9.6 24.0
01718 YF250F-D 6.0

Process:

Selected material , Production, QC inspection ,Packing, Delivery

Certification:

UL ,TUV, ISO9001, ISO14001, Brand name YL

The reason why we are brand enterprise is that the attitude we produce products is same as the first day this company established.

Carefully selected material, strictly QC standards,

we had kept our quality for more than 20 years, developing for 24 years we are more profession.

Company profile:

Suzhou Yuanli Metal Enterprise Co., Ltd was established in 1993 as a wholly Taiwanese invested company,which specializes in the manufacturing of various Ring terminals, Fork terminals, Copper tube terminals, Closed-end terminals, Butt connectors, Blade terminals, Pin terminals, Male and Female terminals.

After 24years development, we are most famous brand name in China.

We passed ISO9001 , ISO14001, TUV

Some products even have obtained the U.S UL certification, also all kinds of terminals have passed SGS test and meet ROHS requirement.

24A 6.6sqmm Fully Electrical Wire Terminals ISO14001 For Electricity Equipment24A 6.6sqmm Fully Electrical Wire Terminals ISO14001 For Electricity Equipment

OEM service

If you have drawings,we can produce for you;

If you have sampels, we can research for you;

If you have requirements, we can customize for you;

We would be your reliable partner and will work out the best solution for you !

Welcome to inquire from us !

Best regards
