Specifications
Brand Name :
Halogen Free Cable
Model Number :
TH-880122
Certification :
UL, CSA, AWM
Place of Origin :
Dongguan, China
MOQ :
3050 meters
Price :
USD0.15~0.40 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000,000 meters monthly
Delivery Time :
10 days for ready goods
Packaging Details :
915 meters per carton, subject to the customized dimensions of product.
Category :
Customized Cable
Feature :
UV Sunlight Resistant
Rated :
80C degree, 300V
Conductor :
PVC Insulated
Jacket :
Polyurethane TPU
Standard :
100% RoHS Compliant
Description

UV Sunlight Resistant Flexible 3C Conductors Customized TPU Cable

Customized Cable is the most featured products of Tongheng business. UV Sunlight Resistant Flexible 3C Conductors Customized TPU Cable is created strictly following customers requirement. As the professional manufacturer, Tongheng staff engage to create customer the best quality cable. UV Sunlight Resistant Flexible 3C Conductors Customized TPU Cable is one of the excellent example. Its remarkable advantage is UV sunlight resistant and very flexible.

Here below is the product properties:

Conductors: oxygen free copper strands.

Jacket materials: high quality polyurethane TPU.

Softness: flexible

Spec to be customized per customer request.

Product parameters:

TPU Cable Conductor Structure Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Conductor Resistance
AWG mm mm % mm mm Ω/KM(20℃)
2C 30 0.23 0.80 ≥65 0.76 3.60 381.0
2C 28 0.23 0.90 ≥65 0.76 3.90 239.0
2C 26 0.23 1.00 ≥65 0.76 4.00 150.0
2C 24 0.23 1.10 ≥65 0.76 4.20 94.2
2C 22 0.23 1.30 ≥65 0.76 4.60 59.4
2C 20 0.23 1.50 ≥65 0.76 5.00 36.7
2C 18 0.23 1.80 ≥65 0.76 5.60 23.2
2C 16 0.23 2.00 ≥65 0.76 7.80 14.6
3C 30 0.23 0.80 ≥65 0.76 5.50 381.0
3C 28 0.23 0.90 ≥65 0.76 5.70 239.0
3C 26 0.23 1.00 ≥65 0.76 5.90 150.0
3C 24 0.23 1.10 ≥65 0.76 6.10 94.2
3C 22 0.23 1.30 ≥65 0.76 6.50 59.4
3C 20 0.23 1.50 ≥65 0.76 7.00 36.7
3C 18 0.23 1.80 ≥65 0.76 7.60 23.2
4C 30 0.23 0.80 ≥65 0.76 5.70 381.0
4C 28 0.23 0.90 ≥65 0.76 5.90 239.0
4C 26 0.23 1.00 ≥65 0.76 6.20 150.0
4C 24 0.23 1.10 ≥65 0.76 6.50 94.2
4C 22 0.23 1.30 ≥65 0.76 6.90 59.4
4C 20 0.23 1.50 ≥65 0.76 7.40 36.7
5C 30 0.23 0.80 ≥65 0.76 6.00 381.0
5C 28 0.23 0.90 ≥65 0.76 6.30 239.0
5C 26 0.23 1.00 ≥65 0.76 6.40 150.0
5C 24 0.23 1.10 ≥65 0.76 6.80 94.2
5C 22 0.23 1.30 ≥65 0.76 7.40 59.4
6C 30 0.23 0.80 ≥65 0.76 6.40 381.0
6C 28 0.23 0.90 ≥65 0.76 6.70 239.0
6C 26 0.23 1.00 ≥65 0.76 7.00 150.0
6C 24 0.23 1.10 ≥65 0.76 7.30 94.2

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the differentt requirement.
