Specifications
Brand Name :
Spiral Cable
Model Number :
TH-812606
Certification :
UL, CUL, CSA, AWM, CE
Place of Origin :
Dongguan, China
MOQ :
200 PCS
Price :
USD0.12~0.55 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800,000pcs per month
Delivery Time :
10 days for ready goods
Packaging Details :
200pcs per carton box
Category :
Spring Cable
Feature :
TPU sheathed, Data use
Rated Temperature :
80 degree
Rated Voltage :
300V
Dimensions :
To be customized per request
Standard :
RoHS Compliant
Description

Self Retracting TPU Sheathed Data Connection Customized Spring Cable

Spring Cable is one of Tongheng main products. Self Retracting TPU Sheathed Data Connection Customized Spring Cable can be customized exactly following customers requirement. As the professional manufacturer, Tongheng staff engage to present customer the best quality article. Self Retracting TPU Sheathed Data Connection Customized Spring Cable is one of the excellent example. Its remarkable advantage is PUR sheathed and data use purpose.

Here below is the product properties:

Conductor: oxygen free copper wire strands

Insulation: Thermoplastic elastomer TPE

Function: data connection

Custom making per customer request.

Product parameters:

Spring Cable Conductor Strands Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Conductor Resistance
No/mm mm mm % mm mm Ω/KM(20℃)
2C 7/0.100 0.38 1.10 ≥65 0.76 4.40 381.00
2C 7/0.127 0.38 1.20 ≥65 0.76 4.50 239.00
2C 7/0.16 0.38 1.30 ≥65 0.76 4.60 150.00
2C 11/0.16 0.38 1.40 ≥65 0.76 4.90 94.20
2C 17/0.16 0.38 1.60 ≥65 0.76 5.10 59.40
2C 21/0.178 0.38 1.80 ≥65 0.76 5.50 36.70
2C 34/0.178 0.38 2.10 ≥65 0.76 6.10 23.20
2C 26/0.25 0.38 2.40 ≥65 0.76 6.90 14.60
3C 7/0.100 0.38 1.10 ≥65 0.76 4.50 381.00
3C 7/0.127 0.38 1.20 ≥65 0.76 4.70 239.00
3C 7/0.16 0.38 1.30 ≥65 0.76 4.90 150.00
3C 11/0.16 0.38 1.40 ≥65 0.76 5.10 94.20
3C 17/0.16 0.38 1.60 ≥65 0.76 5.30 59.40
3C 21/0.178 0.38 1.80 ≥65 0.76 6.00 36.70
3C 34/0.178 0.38 2.10 ≥65 0.76 6.60 23.20
4C 7/0.100 0.38 1.10 ≥65 0.76 4.70 381.00
4C 7/0.127 0.38 1.20 ≥65 0.76 4.90 239.00
4C 7/0.16 0.38 1.30 ≥65 0.76 5.20 150.00
4C 11/0.16 0.38 1.40 ≥65 0.76 5.60 94.20
4C 17/0.16 0.38 1.60 ≥65 0.76 5.90 59.40
4C 21/0.178 0.38 1.80 ≥65 0.76 6.40 36.70
5C 7/0.100 0.38 1.10 ≥65 0.76 4.90 381.00
5C 7/0.127 0.38 1.20 ≥65 0.76 5.10 239.00
5C 7/0.16 0.38 1.30 ≥65 0.76 5.20 150.00
5C 11/0.16 0.38 1.40 ≥65 0.76 5.60 94.20
5C 17/0.16 0.38 1.60 ≥65 0.76 6.20 59.40
6C 7/0.100 0.38 1.10 ≥65 0.76 5.10 381.00
6C 7/0.127 0.38 1.20 ≥65 0.76 5.50 239.00
6C 7/0.16 0.38 1.30 ≥65 0.76 5.90 150.00
6C 11/0.16 0.38 1.40 ≥65 0.76 6.20 94.20

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the different requirement.
