Easy Bounce-back Medical Hospital Bed Coil Spiral Cable
Easy Bounce-back Medical Hospital Bed Coil Spiral Cable
Specifications
Brand Name :
Spiral Cable
Model Number :
spiral-cable-011
Certification :
UL, CUL, CSA, AWM, CE
Place of Origin :
Dongguan, China
MOQ :
200 PCS
Price :
USD0.16~0.45 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800,000pcs per month
Delivery Time :
10 days for ready goods
Packaging Details :
200pcs per carton box
Cable Type :
Coiled spiral cable
Application :
Medical Hospital Bed
Rated Temperature :
90C degrees
Rated Voltage :
300V
Dimensions :
To be customized per request
Standard :
RoHS Compliant
Feature :
Easy bounce-back
Trade or Not :
Factory Direct Sale
Description

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Our coil spiral cable is widely applied, especial the medical hospital use. Best quality of flex performance enables us to earn lots of customers trust and good reputation.

Here below is the product properties:

Conductor materials: Oxygen free copper wires;

Application: medical hospital bed;

Jacket materials: quality polyurethane pur;

100% RoHS compliant.

Product parameters:

Spiral Cable Conductor Structure Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Conductor Resistance
AWG mm mm % mm mm Ω/KM(20℃)
2C 30 0.38 1.10 ≥65 1.15 5.00 381.00
2C 28 0.38 1.20 ≥65 1.15 5.30 239.00
2C 26 0.38 1.30 ≥65 1.15 5.40 150.00
2C 24 0.38 1.40 ≥65 1.15 5.70 94.20
2C 22 0.38 1.60 ≥65 1.15 6.10 59.40
2C 20 0.38 1.80 ≥65 1.15 6.50 36.70
2C 18 0.38 2.10 ≥65 1.15 7.10 23.20
2C 16 0.38 2.40 ≥65 1.15 7.70 14.60
3C 30 0.38 1.10 ≥65 1.15 5.30 381.00
3C 28 0.38 1.20 ≥65 1.15 5.50 239.00
3C 26 0.38 1.30 ≥65 1.15 5.70 150.00
3C 24 0.38 1.40 ≥65 1.15 5.90 94.20
3C 22 0.38 1.60 ≥65 1.15 6.50 59.40
3C 20 0.38 1.80 ≥65 1.15 6.80 36.70
3C 18 0.38 2.10 ≥65 1.15 7.40 23.20
4C 30 0.38 1.10 ≥65 1.15 5.50 381.00
4C 28 0.38 1.20 ≥65 1.15 5.70 239.00
4C 26 0.38 1.30 ≥65 1.15 6.00 150.00
4C 24 0.38 1.40 ≥65 1.15 6.40 94.20
4C 22 0.38 1.60 ≥65 1.15 7.70 59.40
4C 20 0.38 1.80 ≥65 1.15 7.20 36.70
5C 30 0.38 1.10 ≥65 1.15 5.70 381.00
5C 28 0.38 1.20 ≥65 1.15 5.80 239.00
5C 26 0.38 1.30 ≥65 1.15 6.00 150.00
5C 24 0.38 1.40 ≥65 1.15 6.40 94.20
5C 22 0.38 1.60 ≥65 1.15 7.00 59.40
6C 30 0.38 1.10 ≥65 1.15 5.90 381.00
6C 28 0.38 1.20 ≥65 1.15 6.30 239.00
6C 26 0.38 1.30 ≥65 1.15 6.70 150.00
6C 24 0.38 1.40 ≥65 1.15 7.00 94.20

Product image:

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable

Easy Bounce-back Medical Hospital Bed Coil Spiral Cable
