5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine
5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine
5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine
5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine
Specifications
Brand Name :
SHENGHONG
Model Number :
JJM-5SQ
Certification :
ISO
Place of Origin :
MADE IN CHINA
MOQ :
1set
Price :
USD2000-3000
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
15 days after deposite
Packaging Details :
Plywood case
Selling Point :
Double Capstan Winch
Type :
Gasoline Winch
Engine :
Honda Gasoline engine
Power :
13HP
Weight :
300kg
Capstan :
Double Capstan
Suitable Wire Rope :
≤15mm
Dimension :
1300x800x600mm
Description

5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine​

Quick details

1. Transimission line stringing tools

2. Dual-bull wheel powered winch

3. Groove number 7

4. Pull force 50kn

5. weight: 300kg

Application
Extensively applied to an under construction set of electric power, post and tele wire ways to tower group sets up the pole.Apply to use in the wild non-transformer station, it will be convenient and agility.

Uses

apply to hoisting mechanical equipments and erecting pole pylon . hauling and string conductors in post telephone. telegraph and electric power lines .


Feature

the whole machine is mounted on a framework with wheel hub for easy transportation.

Data sheet

Model JJM-5SQ/JJM-5SC
Engine HODNA GX390/186F Diesel Engine
Power 13HP,3600rpm/6.3KW,3600rpm
Suitable Wire Rope(mm) 15
Bottom diameter of Groove(mm) 240
No. Of Groove 6
Gear Forward Reverse
Slow I Slow II Fast I Fast II Slow Fast
Pull Force(KN) 50 30 13 10 No lifting No lifting
Speed(m/min) 6 10 23 30 5 17
Weight(KG) 280/300
Dimension(mm) 1330×800×600

Packing

5 Ton Electric Cable Pulling Winch / Double Capstan Winch With Honda GX390 Gasoline Engine
