10 Ton Electronic Wireless Dynamometers Dyna-link Dynamometer
10 Ton Electronic Wireless Dynamometers Dyna-link Dynamometer
10 Ton Electronic Wireless Dynamometers Dyna-link Dynamometer
10 Ton Electronic Wireless Dynamometers Dyna-link Dynamometer
Specifications
Brand Name :
SHENGHONG
Model Number :
DL-W3-10
Certification :
ISO
Place of Origin :
MADE IN CHINA
MOQ :
5pcs
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50pc/day
Delivery Time :
10 days after payment
Packaging Details :
carton
Type :
Electronic Wireless Dynamometers
Capacity(Kg) :
10000
Division(Kg) :
5
Selling point :
High Strength
Material :
Steel
Warranty :
1 year
Description

10 Ton Electronic Wireless Dynamometers Dyna-link Dynamometer

Features

1. Rugged Construction
2. Accuracy "0.05 % of capacity
3. All fuctions and units are clearly display on the LCD(with back- lighting).
4. Digits are 1 inch high for easy distant viewing
5. Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.
6. Long battery life on 3 standard "LR6(AA)"Size alkaline batteries.
7. All commonly used internationally recognized units are available; kilograms (kg) , short Tons (t) Pounds (lb), Newton and kilonewton(KN).
8. Infrared Remote control easier to calibration(With password )
9. Infrared Remote control with many functions:"ZERO","TARE","CLEAR","PEAK","ACCUMULATE","HOLD","Unit Change","Voltage check" and "Power OFF".
10. 4 local mechanical keys: "ON/OFF","ZERO","PEAK"and "Unit Change".
11. Low battery warning.
12. RF wireless palm indicator.

Data Sheet

MODEL CAP Div A(mm) B(mm) C(mm) D(mm) φ(mm) H(mm) Material
DL-W3-1 1t 0.5kg 245 112 37 190 43 335 Aluminum
DL-W3-2 2t 1kg 260 123 37 195 51 365 Aluminum
DL-W3-3 3t 1kg 260 123 37 195 51 365 Aluminum
DL-W3-5 5t 2kg 285 123 57 210 58 405 Aluminum
DL-W3-10 10t 5kg 320 120 57 230 92 535 Alloy Steel
DL-W3-20 20t 10kg 375 128 74 260 127 660 Alloy Steel
DL-W3-30 30 10kg 420 138 82 280 146 740 Alloy Steel
DL-W3-50 50t 20kg 465 150 104 305 184 930 Alloy Steel
DL-W3-100 100t 50kg 570 190 132 366 229 1230 Alloy Steel
DL-W3-200 200t 100kg 720 265 183 440 280 1362 Alloy Steel


Body protection: Aluminum and alloy steel capacities are powder coated.
It is an extremely well-built instrument for industry use ,as a standard wireless tool offer universal applications,Whether used as conventional crane weigher or to measure force, DL-W3 wireless dynamometer is microprocessor controlled for high precision accuracy, calibration is easier with wireless handheld indicator.profile:

Accuracy: 0.05% for 1-50t, 0.1% for above 50t capacity.

Units: Units are clearly display on the screen, available in the following measurment reading: kilograms(kg), short Tons(t) pounds(lb), Newton and kilonewton(kN)

Shackles: High tension industrial standard G2130 anchor shackle bows, galvanized finish.Gravity regulation: The acceleration of gravity can be regulated through indicator parameter setting according to different places value.

Functions: wireless indicator with many functions: Zero, tare, Low battery warnings, peak hold, overload warning. User calibration(with password).

Set-Point: Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.

Package: Packed with carry case, easy to bring.
