630 Rigid Strander with Auto-Loading PN1600 End-Shaft Pay-off Stand​

1.Features

As a result of technical innovation and optimized design, rotating speed of the stranding case increases by more than 15% and technical properties are more updated.

Applicable to stranding copper conductor, aluminum conductor, and aluminum conductor steel reinforced (ACSR) without backtwist, as well as insulated wire and strand. Fitted with a compactor, it is also applicable to stranding round-shaped, semi-round-shaped, and sector-shaped copper conductor or aluminum conductor.

Applicable to PND 630 bobbins, provided with hanger and electric hoist to load and unload the bobbin individually or side-bottom batch loader to load and unload the bobbins altogether.

Bobbins are loaded separately in four equal positions on the circumference of the stranding cage to make it easy to load and unload. The machine features high rigidity, good integrity, and small inertia of rotation, and high running speed.

2.Configuration

2.1. Basic: FN1600 end-shaft pay-off stand, stranding cage, hanger for individual bobbin loading, adjustable closing die stand, main reducer and 36-gearbox, length counter, twin motorized capstans with natural conductor divider, 2500 end-shaft take-up with traversing unit, DC motor and DC speed regulator, electric control cabinet and operation desk, sliding safety fence.

2.2. At user’s option: shaft-type pay-off stand, batch loader, ultrasonic controller for tension from bobbin, closing die stand and roller compacting unit, gantry travel take-up with traversing unit, AC motor and variable frequency speed regulator, curved sliding fence or motorized rotating safety fence.

3.Technical Parameters of JLK 500 Series

Technical Parameters of JLK 630 Series
