UL2464 300V 10MΩ white one out three insulation waterproof anti oxidation refrigerator wiring harness

1. Product description

Structure and Materials:

Conductor material: pure copper
Conductor specification :18AWG (1.02mm²)
Insulation material: white PVC
Insulation thickness :0.76mm
Outer sheath material: white PVC
Outer sheath thickness :1.14mm

Electrical Performance:

Rated voltage :300V
Insulation resistance :≥10MΩ
Withstand voltage :1500V for 1 min
Operating temperature range :-20°C to +105°C
Mechanical properties:

Bending radius :≥3D (D is the outer diameter of the wire)
Tensile strength :≥6.0kgf
Tensile strength :≥9.0kgf

Environmental performance:

Waterproof grade :IP68
Chemical corrosion resistance
Ozone resistance
Flame retardant grade :UL94 V-0

2. Product information

3. Picture of real products

4. Features

I: One out three structure: there are three independent output wires. It is convenient to connect with different interfaces of refrigeration equipment, which improves the flexibility and applicability of the system.

II: Ultra-high insulation resistance: Insulation resistance up to 10 megapohms, greatly reducing the risk of leakage and short circuit, improve electrical safety. The harness maintains excellent insulation even in humid environments.

III: Waterproof and anti-oxidation design: The wire harness is made of white PVC insulation material and outer sheath, which has excellent water resistance and anti-oxidation ability. It can effectively resist the erosion of dampness, rain, chemicals and other harsh environmental factors to ensure long-term stable and reliable operation.

5. Product application

I: Refrigeration compressor.

II: Refrigeration equipment motor.

III: Refrigeration control system.

IV: Outdoor, commercial refrigeration equipment.
