Automatic FM200 Fire Suppression System Without Pollution For Power Room

This advanced system is designed to extinguish fires quickly, effectively, and without causing harm to people or the environment.

The FM200 Fire Suppression System is based on a colorless, odorless, and electrically non-conductive chemical agent that can extinguish fires through a combination of chemical and physical mechanisms. The chemical agent, HFC-227ea (1,1,1,2,3,3,3-Heptafluoropropane), is a clean and safe alternative to traditional fire suppression agents such as halon and CO2.

One of the key benefits of the FM200 Fire Suppression System is its ability to suppress fires rapidly, minimizing damage to critical assets and reducing downtime. The system can extinguish fires within 10 seconds, providing a quick response to any fire emergency. Additionally, the FM200 Fire Suppression System is safe for use in occupied spaces and does not leave any residue or oily deposits.

Physical and chemical properties

Chemical Formula: The FM200 (Heptafluoropropane, HFC-227ea) Fire Suppression System uses a synthetic, organic compound called heptafluoropropane (HFP) as its active agent. The chemical formula for HFP is C3HF7.

1.Colorless and Odorless: FM200 (Heptafluoropropane, HFC-227ea) is a colorless, odorless gas that is difficult to detect without specialized equipment.

2.Non-Corrosive: FM200 (Heptafluoropropane, HFC-227ea) is non-corrosive, meaning it does not react with or damage metals, plastics, or other materials commonly found in buildings and equipment.

3.Low Toxicity: FM200 (Heptafluoropropane, HFC-227ea) has a low toxicity level, which means it is safe for human occupancy when used in accordance with design and installation guidelines.

4.High Boiling Point: FM200 (Heptafluoropropane, HFC-227ea) has a high boiling point of 16.4 °C (61.5 °F), which means it remains in a gaseous state at room temperature and pressure. This property allows it to quickly disperse and distribute throughout an enclosed space to suppress a fire.

5.Non-Conductive: FM200 (Heptafluoropropane, HFC-227ea) is non-conductive, which means it does not conduct electricity. This property makes it safe to use in areas where electrical equipment is present.

6.Low Global Warming Potential: FM200 (Heptafluoropropane, HFC-227ea) has a low global warming potential (GWP) of 0.02, which is much lower than other commonly used fire suppression agents such as halon.

7.Rapid Extinguishing Action: FM200 (Heptafluoropropane, HFC-227ea) can extinguish fires quickly by removing heat from the fire triangle, interrupting the chemical chain reaction, and reducing the concentration of oxygen in the protected space.

Components

Pipe network fm200 fire suppression device is composed of the follow-up components: fm200 agent, fm200 cylinders, container valves, flexible hoses, liquid flow check valves, a set of manifold, a safety valve, pressure switch, nitrogen driving device(s), driving device frame, gas control pipe, gas flow check valves(it depends), selective valves(it depends), a pair of elbows and flanges, nozzles.If one set device needs to protect multiple protected zones, its composition is as above. However, if one set system just needs to protected single protected zone, the gas flow check valve and the selective valve should be got rid of from its composition.

Application

The FM200 Fire Suppression System is suitable for a wide range of applications, from small server rooms to large data centers and industrial facilities. It is also easy to install, maintain, and recharge, making it a cost-effective choice for those seeking a reliable and efficient fire suppression system.

Advantages

The FM200 Fire Suppression System is one of the most advanced fire suppression systems available today. It is designed to provide a fast and effective response to fire emergencies while minimizing damage to critical assets and preserving the safety of people and the environment.

One of the key advantages of the FM200 Fire Suppression System is its chemical and physical properties. The chemical agent, HFC-227ea, is a colorless, odorless, and electrically non-conductive gas that is safe for use in occupied spaces. It is also non-corrosive, non-toxic, and does not leave any residue or oily deposits after use. This makes it an ideal choice for use in sensitive areas such as data centers and museums.

Packages

We always pack it with polyfoam firstly and then put it into a wooden case. Sometimes, in order to meet with customers or the safety requirement, we will make a pallet for the goods.
