Specifications
Brand Name :
Garant Optima
Model Number :
GO-LODX-250
Certification :
CE,FCC,ROHS
Place of Origin :
China
MOQ :
2 sets
Price :
2200~5000USD/㎡
Payment Terms :
T/T, Western Union
Supply Ability :
10000㎡/month
Delivery Time :
15~30 days
Packaging Details :
Anti-shaking wooden cabinet /Air flight case/carton
Pixel Pitch :
2.5mm
Power Brand :
Rxpower,Giant G-energy,Powerld,MeanWell
IC :
SM16169S
Controlling System :
linsn, Nova, Mooncell,XiXun
LED Shape :
SMD3 in 1
LED Configuration :
SMD1415(1R1G1B)
Module Size :
256x128 mm
Led Lamp Brand :
HongSheng,NationStar
Brightness :
≥6000 cd//㎡
IP Rating :
IP65/IP54
Environment :
Outdoor
Description

The outdoor P2.5 fine pitch light pole led display also named as P2.5 flag led display or P2.5 outdoor small pitch light pole led screen,which is specially designed for smart city by Garant Optima. Compared with traditional outdoor P3 light pole screens ,P3.33 flag led screen and P4,P5 light pole led poster,it's flater and better viewing effect,which really achieves seamless stitching. It adopts GarantOptima's unique 320x160mm outdoor p2.5 led modules . the brightness is high to make sure clearer image during daytime; with masks protection to makes it more stable. The P2.5 outdoor Led kiosk screen are often installed on street lamp poles, and are suitable for pedestrian streets, highways, sides of streets and other roads, or communities with high traffic. As an outdoor led flag screen, it has synchronous reception and synchronous playback functions. When you walk in the area covered by the LED light pole screen, all screens are always playing high-definition content, how much impact on your vision!

Advantage

1,Clearer and better picture

2,Integrated design, simple operation;

3,The rear seat and the side of the column can be optionally installed, which is easy to transport and install;

4,Built-in synchronous and asynchronous control card, which can realize intelligent management and large-scale cluster control, simple and convenient;

5,Manage multiple display screens via cable, 3G, 4G, WAN,LAN or via APP via mobile phone (1-1 and 1-N manage to set time, update AD etc)

Main Functions:

smart city double sided outdoor P2.5 fine pitch light pole led display screen for ads

√ Smoke/humidity temperature detecting

√ Large scale cluster scale cluster control and management

√ Free Wifi

√ High brightness and energy saving

Selectable Functions

smart city double sided outdoor P2.5 fine pitch light pole led display screen for ads

√ GPS

√ Face recognition

√ Smart interactive voice and video

√ Free charge port

Parameter

LED Display Model GO-LODX-250
Terminal Screen Customized
Pixel Pitch 2.5mm
Pixel Density 160000dot//
LED Shape SMD 3in1
LED Configuration SMD1415(1R1G1B)
Module Size 320x160 mm
Module Resolution 128*64dot
Terminal Screen Resolution 128Ax64B dot
Screen Size 320Ax160Bmm
Terminal Size Customized
Cabinet Material Waterproof Cabinet(Iron/Aluminum)
Cabinet Weight 55Kg/
Brightness ≥5500 cd//
Viewing angle H/V 140/140
Viewing Distance ≥3Meters
Display Color 16.7M
Refresh Rate ≥1920Hz
Grey Scale 14Bit
Scanning Mode 16S
IP Rating IP65/IP54
Max power consumption 1000 W/
Ave power consumption 330 W/
Working Voltage AC 100-240V, 50-60HZ
Control Mode Synchronous control/Asynchronous control
Data Transmission CAT5/ Optic Fiber
Controlling system Linsn, Nova, Mooncell,Xixun
Video signal input 3G, 4G, WAN,LAN
Working Temperature -20~65 ℃±10%
Working Humidity 10-90% RH
Brightness Adjustment 0~100 levels
Life Span 100,000 Hours
Pixel failing Rate 0.0001
Working Environment Outdoor

Other Size:
640x480mm outdoor P2.5 led light pole screen

640x800mm P2.5 outdoor led flag screen

640x960 mm outdoor P2.5 small ptich Led kiosk screen

480x960mm P2.5 outdoor fine pitch light pole led display

Application

P2.5 outdoor led flag screen in Suzhou

smart city double sided outdoor P2.5 fine pitch light pole led display screen for ads

P2.5 outdoor led kiosk screen in GuangDong

smart city double sided outdoor P2.5 fine pitch light pole led display screen for ads

Double sided P2.5 outdoor light pole led display for NanJing
smart city double sided outdoor P2.5 fine pitch light pole led display screen for ads

Looking for P2.5 HD light pole led screen Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Easy Opertation Led Poster are quality guaranteed. We are China Origin Factory of p2.5 outdoor light pole led display. If you have any question, please feel free to contact us.This P2.5 outdoor LED screen can not only be used for road guidance, road broadcasting, information dissemination, advertising, but also can play an important role in alleviating driver fatigue.
