Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
Specifications
Brand Name :
Garant Optima
Model Number :
GO-OM3.33
Certification :
CE,FCC,ROHS
Place of Origin :
China
MOQ :
200pcs
Price :
18~36usd/pcs
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs/month
Delivery Time :
7~15 working days
Packaging Details :
48pcs each carton with pearl cotton protection
Pixel Pitch :
3.33mm
Led configuration :
SMD1921
Size :
160x160mm
Resolution :
48x48dot
N.W :
0.25Kg
Current :
≤4.6A
Brightness :
≥6500CD
Ave consumption :
8.5W/pcs
Scanning Mode :
12S
Description

Outdoor P3.33 Led Display Module

With the development of technology and the improvement of people's visual requirements, outdoor small pitch LED screens have become more and more popular. At present, the cost of outdoor P3 Led displays is quite high, but Garant Optima' independently developed 160x160mm 48x48dot outdoor P3.33 LED modules will change this situation.It adopts SMD1820 / 1921 high-quality lamp,which compared with traditional outdoor P3 (using SMD1415 lamps) LED modules,the cost is greatly reduced and the performance is the same.

Features:

1,low consumption≤8.5W each PC

2,high brightness≥6500CD

3,low electric current≤4.6A

4,mask protection

Advantage:

1,160x160MM size design to make the terminal screen more flexible

2,4 layers high standard PCB,V0 grade fireproof kits

3,seamless splice module&delicate screen

4,cost effective SMD1921(compared with 1415) led lamps with mask protection,more stable

Specification

Model GO-OM3.33
Pixel Pitch 3.33mm
LED Configuration SMD1921(3 in 1)
Module Size: 160x160mm
Module Resolution 48*48
Module Weight 0.25kg
Module Voltage 4.8-5.5V DC
Module Current ≤4.6A
Module Consumption 8.5W/pc
Brightness >6500nits
Scanning Mode 12S
View Angle 140°
View Distance >4m
Protection Level IP65 Waterproof
Warranty 1Year Warranty default
Certificates CE,RoHS,FCC,IP65 Approved
Operation Temperature -20°--50°

Application:

The outdoor P3.33 led modules are widely used for outdoor fixed installation, light pole screen, advertising machines and other outdoor LED display. Welcome consult from oversea friends!

Ex:light pole led display example

Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen

Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen

fixed installation for video wall

Factory direct sale full color SMD1921 P3.33 outdoor led display module with mask protection for light pole led screen
