P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
P2.85 full color outdoor led module for outdoor fine pitch led video wall&light pole led screen
Specifications
Brand Name :
GOTECH
Model Number :
GO-OM2.85
Certification :
CE,FCC,ROHS
Place of Origin :
CHINA
MOQ :
100pcs
Price :
23~40usd/pcs
Payment Terms :
T/T
Supply Ability :
50000pcs/month
Delivery Time :
2~15 working days
Packaging Details :
56pcs/ carton
Pixel Pitch :
2.85mm
Pixel Density :
123114dot/m²
Module resolution :
64×64
Best viewing distance :
>3m
Brightness :
5500cd/m²
Driving method :
Constant current
Description

P2.85 outdoor led module

P2.85 outdoor LED module is an outdoor small-pitch LED module independently researched and developed by GOTECH. It uses Nationstar 1415 SMD led lamps, 160x160mm 4-layer high standard PCB board, V0 fireproof bottom shell and exquisite protective mask, the screen body combination is flexible and changeable, the screen display is delicate and beautiful, and the product performance is stable and reliable.

Specification

Product model GO-OMS2.5 GO-OMB2.5 GO-OM2.85 GO-OM3 GO-OM3.33 GO-OM3.57 GO-OM3.84
Pixel Pitch 2.5mm 2.5mm 2.5mm 3mm 3.33mm 3.57mm 3.84mm
Pixel Density 160000dot/m² 160000dot/m² 123114dot/m² 111111dot/m² 111111dot/m² 78462dot/m² 67816dot/m²
Pixel Configuration SMD1415(1R1G1B) SMD1415(1R1G1B) SMD1415(1R1G1B) SMD1921(1R1G1B) SMD1921(1R1G1B) SMD1921(1R1G1B) SMD1921(1R1G1B)
Module size 160x160MM 320x160MM 160x160MM 192x192MM 160x160MM 200x200MM 200x200MM
Module resolution 64×64 128×64 56×56 64×64 48×48 56×56 52×52
Module maximum current 3.5A 7A 4.5A 7A 5A 5.8A 6.3A
Ave Module consumption 10.5W 21W 13.5W 21W 15W 15W 19W
Max Module consumption 17.5W 35W 22.5W 35W 25W 17.5W 31.5W
Average power consumption 200W/m² 200W/m² 530W/m² 570W/m² 585W/m² 450W/m² 475W/m²
Max power consumption 650W/m² 650W/m² 880W/m² 950W/m² 980W/m² 750W/m² 790W/m²
Module Weight 0.25KG 0.45KG 0.22KG 0.3KG 0.25KG 0.35KG 0.35KG
Installation rear rear rear rear Rear/Front Rear Rear
Best viewing distance >2.5m >2.5m >3m >3.5m >4m >4.5m >4.5m
Brightness 5000cd/m² 5000cd/m² 5500cd/m² 6000cd/m² 6000cd/m² 6000cd/m² 6000cd/m²
Scan mode 16S 16S 14S 16S 12S 14S 13S
Refresh Rate >1920Hz >1920Hz >1920Hz >960Hz >960Hz >960Hz >960Hz
Best viewing angle ≤140° ≤140° ≤140° ≤140° ≤140° ≤140° ≤140°
Color value >16.7M >16.7M >16.7M >16.7M >16.7M >16.7M >16.7M
Gray scale 16bits 16bits 16bits 16bits 16bits 16bits 16bits
Color temperature 6500K 6500K 6500K 6500K 6500K 6500K 6500K
Driving method Constant current Constant current Constant current Constant current Constant current Constant current Constant current
Frame-changing frequency 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ 60HZ
Control level 256 256 256 256 256 256 256
MTBF 10,000H 10,000H 10,000H 10,000H 10,000H 10,000H 10,000H
Life span 100,000H 100,000H 100,000H 100,000H 100,000H 100,000H 100,000H
Working Voltage DC5V DC5V DC5V DC5V DC5V DC5V DC5V
Working Temperature -20~65 ℃±10% -20~65 ℃±10% -20~65 ℃±10% -20~65 ℃±10% -20~65 ℃±10% -20~65 ℃±10% -20~65 ℃±10%
Working Humidity 10-90% RH 10-90% RH 10-90% RH 10-90% RH 10-90% RH 10-90% RH 10-90% RH
Brightness Adjustment 0~100 levels 0~100 levels 0~100 levels 0~100 levels 0~100 levels 0~100 levels 0~100 levels
Pixel failing Rate 0.0001 0.0001 0.0001 0.0001 0.0001 0.0001 0.0001
Working Environment Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor

Application:

Outdoor P2.85 full-color led modules are widely used in outdoor high-definition LED light pole screens, high-definition LED advertising machines, vehicle-mounted high-definition advertising panels and some fixed installation LED video walls
