VGA-KVM Fiber Optic Extender

Description

The vga kvm fiber optic extender also named as vga kvm to fiber optic converter or vga kvm switch to fiber,which transmits 1ch uncompressed 1080p vga signal,usb1.1 keyboard and mouse signals and external independent audio signals through a single-mode fiber, which can adapt to a variety of complex application environments The device's superior image processing and transmission capabilities make signal transmission smoother and more stable.

Features

• Long-distance transmission of VGA video and audio signals over singlemode fiber, up to 20 km;
• HD uncompressed video signal resolution up to 1080P-60Hz;
• Comply with the VGA standard protocol;
• Support for external analog stereo audio signal transmission;
• Support local 1 channel VGA signal output; remote 1 channel VGA signal output, 1 channel dvi signal output
• Support 232 serial data bidirectional transmission, adaptive baud rate;
• Ability to automatically identify and configure various display modes;
• Built-in automatic adjustment system, make the image smooth, clear and stable;
• Built-in ESD protection system;
• Simple to install, plug and play;
• Support USB1.1 Mouse and keyboard remote operation

Specifications

Panel Diagram

Transmitte &Receiver

Package list

VGA fiber transmitter ………. 1 pc

VGA fiber receiver ……………. 1 pc

Power adapter ………………………………..2 pcs

User manual ………………………………….. 1 pc

Installation

1. Connect the VGA signal source to the VGA fiber transmitter.

2. Connect stereo audio to the VGA optical transceiver (if needed).

3. Connect the VGA connector of the receiver end to the display device (such as HDTV, splicing screen, etc.).

4. Connect the output audio of the receiver to the audio equipment (if needed).

5. Connect the fiber between the transmitter end and the receiver end.

6. Connect the transmitter and receiver to the power supply. When the indicator light is on, the system runs normally.

7. Connect the USB interface of the computer to the USB interface of the transmitter, and connect the keyboard and mouse to the USB interface of the receiver to implement the KVM function.

Application Connection Diagram

VGA fiber extenders are widely used in large-scale multimedia high-definition display, information release and news centers, traffic guidance and information display systems, outdoor large-screen display systems, large-scale stage display and entertainment centers, live television broadcasts, multimedia conferences, military command and exercises fields etc.
