Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Sunnran
Price :
Negotiable
MOQ :
1
Delivery Time :
150 working days
Packaging Details :
Wooden case
Type :
Packaging Line
Applicable Industries :
Food & Beverage Factory
Showroom Location :
None
Condition :
New
Application :
Aerosol can making
Packaging Type :
CANS
Packaging Material :
Metal
Automatic Grade :
Automatic
Driven Type :
Electric
Voltage :
220V/380V/440V
Weight :
7000 KG
Warranty :
1 Year
Key Selling Points :
High Productivity
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
PLC
Capacity: :
Max.550CPM
Rectangular can diagonal: :
70-200 / 200-300mm
Can Diamete: :
52-73mm
Machine type: :
Packing Line Solution
Function: :
Produce the metal can
After Warranty Service :
Video technical support
Local Service Location :
None
Description
Products Description
Aerosol can combination machine flanger necker seamer seamer
Can add pre-necking station, suitable for various tinplate , especially for DR material . Vertical design makes it easy to connect with other machine. Equipped with Recyclable central lubricating system . Use inverter for various speed control Fully automatic control system. Multi-safety design for machine and operator’s safety. No-can, no-cover protection system. Equipped with two separating knives on cone and dome magazine. With safety cover and automatic height adjuster.
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Function
Dia. range
Height range
Max speed
Pre-necking ( For DR material)
45-73mm
90-320mm
400CPM
Necking + flanging
45-73mm
90-320mm
400CPM
seaming
45-73mm
90-320mm
400CPM
Remarks: Combination machine type is decided by customer’s can type.
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Auto Welder
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Capacity:
Tinplate thickness
Diam of copper wire
Welding speed
Welding frequency
500 cans/min
0.16-0.30
1.38mm or 1.50mm
9-57m/min
100-650hz
Can Dia
Can height
Can height
Overlap
Transformer Power
φ52-153
52-99
60-320mm
0.4mm
150Kw
Side stripe powder coating system
Characteristics:
Steady even application Clean and clear side stripe No powder dropping and splashing No environmental pollution, No powder leaking
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Speed
Stripe width
Can size
Power
Power supply
Air
Max. 90m/min
6-12mm
52-400mm
2Kw
380V, 3Phase
6 bar, 500L/min
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Induction oven
It works based on the SPWM technology, generating vortex heating by A/C on the welding seam area for curing . Induction oven is characteristic with energy saving , environment-friendly & safety. It fits different can sizes and different speed of production line.
Output frequency
Diameter
Max power
Cooling type
20-30Khz
52-180mm
1.5Kw/ heating coil
Air cooling / water cooling

Pressure leakage tester
Automatic Tin Can Seamer Machine , 73mm Can Flanger Machine 550CPM
Characteristics
Non-destructive testing
Imported European high precision transducer, more reliable Equipped with temperature compensation system to improve accuracy With more humanized interface for operation With automatic height adjustment to make changeover more easy
Applicable can type
Testing head Qty.
Height range
Diameter range
Precision
Max. speed
Compressed air
Aerosol can
48
80-320
45-65
≥2cc 8bar/Min
400CPM
3m³/Min 8-12bar
36
80-320
45-65
≥2cc 8bar/Min
320CPM
24
80-320
45-65
≥2cc 8bar/Min
220CPM
Powder can
20
110-245
99-153
0.03-0.05mm, 0.02Mpa
200CPM
15
110-245
99-153
150CPM
About us

We are a professional manufacturer & exporter specialized in various tin cans making machinery.

As a rich experienced manufacturer & exporter in this field, we always make the most suitable solutions for customers in tin cans / ends making.

‘High quality, competitive price & superior after-sale service’ is our principle.

We are always ready to develop long-term and good relationship with overseas customers.

We provide the following series of products:

Automatic Lid / Ring / Bottom Production Lines

Automatic EOE (easy open ends) Production Lines

Automatic Aerosol Cone / Dome Production Lines

Automatic Twist-off Lug Cap Production Lines

CNC Feeding System

Automatic Palletizer

Automatic Depalletizer

Wrapping Machine

Conveyor Device

Automatic Aerosol Tin Can Production Lines

Automatic Food Tin Can Production Lines

Automatic Beverage Tin Can Production Lines

Automatic Chemical Tin Can Production Lines

Semi-automatic 1-5L Round / Square / Rectangular Tin Can Production Lines

Semi-automatic 10-20L Paint Bucket Production Lines

Semi-automatic 15-18L Square Tin Can Production Lines

Semi-automatic 40-60L Bucket Production Lines

Press Dies and welding spare parts

And so on......

‘To be the best supplier’ is the attitude of our company.

We will keep on providing modern and advanced machines to bring greater value-added benefit for our customers.

If you want to know more about us, please don’t hesitate to contact us at any time.

Welcome to our company!
