2T/H Pet Canned Food Production Line Equipment Meat Canning Food Line CE

LWT provides you with a complete set of equipment for pet canned food production line. We provide you with whole plant planning and design as well as customized services.

Pet canned food production line capacity:

40 cans/minute.

Material: beef

Packaging material: tinplate cans

Process flow:

Minced meat - chopping and mixing - vacuum mixing - material cart lifting - empty can cleaning - filling - sealing - cleaning - cage loading - sterilization - cage unloading - drying - labeling - unpacking - packing - palletizing - winding

The following is an overview of these equipment and their role in the production process:

1. Meat grinder

lFunction: Cut the raw meat into a size suitable for processing.

lFeatures: Can handle frozen meat with a maximum size of 600*400 25mm, keep the meat temperature at 0-2℃, have a feed conveyor, and a productivity of up to 2-3t/h.

2. Chopper

lFunction: Further cut the meat into a paste.

lFeatures: large capacity, variable speed of blade and bowl, hydraulic drive for unloading, suitable for material temperature of 0~5℃.

3. Vacuum mixer

lFunction: evenly mix meat with other additives.

lFeatures: 1200L tank volume, high vacuum, adjustable stirring speed, moderate power.

4. Material car elevator

lFunction: used for material storage, transportation and feeding.

lFeatures: The elevator is convenient for feeding materials into the mixer, and the meat car is used for storage and transportation of materials in the production line.

5. Empty can cleaning machine

lFunction: clean empty cans and prepare for filling.

lFeatures: steam cleaning is adopted, and the motor is protected by a stainless steel cover to ensure cleaning effect and equipment safety.

6. Meat sauce filling machine

lFunction: fill the mixed meat sauce into empty cans.

lFeatures: fast filling speed, wide filling range, moderate gas consumption.

7. Weight detector

lFunction: Check the weight of filled cans to ensure compliance with standards.

lFeatures: High sorting accuracy, wide range of applications, easy operation.

8. Vacuum sealer

lFunction: Vacuum seal filled cans.

lFeatures: Fast sealing speed, wide range of applications, moderate motor power.

9. Full can cleaning machine

lFunction: Clean the sealed cans to remove surface stains.

lFeatures: Steam heating and hot water cleaning, conveyor line outlet with twisting cage for easy subsequent processing.

10. Semi-automatic loading and unloading cage

lFunction: Assist workers to load and unload cans layer by layer into and out of sterilization baskets.

lFeatures: Hydraulic system + cage mechanism, moderate production speed.

11. Sterilizer

lFunction: Sterilize cans.

Features: moderate power consumption and steam consumption,

canned and bagged products can be shared,

with steam function and hot water tank.

12. Tornado Dryer

lFunction: Dry the sterilized canned food.

lFeatures: fast drying speed and moderate equipment power.

13. Paste Labeler

lFunction: Label the canned food.

lFeatures: fast labeling speed, wide application range, adjustable label size.

14. Unpacking-packing-sealing machine

lFunction: Put the canned food into the carton and seal it.

lFeatures: easy to operate, suitable for cartons of different sizes.

15. Semi-automatic wrapping machine

lFunction: Stretch the packaged cartons on the pallet.

lFeatures: large turntable diameter, high packaging height, strong load-bearing capacity.

This pet canned food production line is fully equipped with a high degree of automation to ensure production efficiency and product quality. At the same time, the equipment is tightly connected and easy to operate, making it convenient for workers to carry out daily maintenance and operation.
