240V Automatic Voltage Regulator Of AC Generator
240V Automatic Voltage Regulator Of AC Generator
240V Automatic Voltage Regulator Of AC Generator
240V Automatic Voltage Regulator Of AC Generator
Specifications
Brand Name :
ACEPOW
Model Number :
DVR2000E
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T
Supply Ability :
10000SETS/YEAR
Delivery Time :
25 DAYS
Packaging Details :
CARTON BOX
type :
Generator AVR DVR2000E
Input voltage :
180-240V AC 50/60HZ
Stock :
Stock supply for AVR DVR2000E
Frequency :
50-60Hz nominal
Voltage regulate :
≤ ± 0.25%
Usage :
Underfrequency (volts/hertz) regulation.
Model number :
AVR DVR2000E
Warranty :
1 year
Description

Generator AVR DVR2000E Marathon Used AC Brushless Alternator Generator Voltage Regulation

Specification
- Dvr 2000e marathon generator regulates the output voltage of a brushless, ac generator by controlling the current into the generator exciter field. Input power to the DVR2000E is from a multi-pole, high-frequency, permanent magnet generator (PMG).

- Generator digital AVR DVR 2000E is supplied in an encapsulated package designed for behind-the-panel mounting.

The DVR2000E is held in place by thread-forming screws that thread into its plastic shell. Front panel indicators (LEDs) annunciate regulator status and system conditions. DVR2000E connections are made through quarter-inch, quick-connect terminals on the rear panel. A 9-pin DB-9 type connector on the rear panel provides communication between the DVR2000E and an IBM compatible PC.

Dvr 2000e marathon generator replaced type
Sensing Input voltage 180-240V AC 50/60HZ
Power input voltage 180-240V AC 50/60HZ
Output current Max 90VD@207AC,Continuous 4A dc,Intermitten 10A for 10s.
Volts adjustment ± 8% within 1K Ohm
UFRO Slop 17% down to 30Hz
Volts regulation ≤ ± 0.25%
Four control modes: automatic voltage regulation (AVR), manual or current regulation (FCR), power factor (PF) regulation, and reactive power (VAR) regulation.
Function List • Programmable stability settings.
• Soft start control with an adjustable time setting in AVR control mode.
• Overexcitation (OEL) limiting in AVR, VAR, and PF control modes.
• Underfrequency (volts/hertz) regulation.
• Crowbar circuitry protects the area.
• Overtemperature protection.
• Three-phase or single-phase generator voltage (RMS) sensing/regulation in AVR mode.
• Single-phase generator current sensing for metering and regulation purposes.
• current and voltage sensing.
