43KVA 34KW Canopy Diesel Generator , Electric Start Silent Generator
43KVA 34KW Canopy Diesel Generator , Electric Start Silent Generator
43KVA 34KW Canopy Diesel Generator , Electric Start Silent Generator
43KVA 34KW Canopy Diesel Generator , Electric Start Silent Generator
Specifications
Brand Name :
ACEPOW
Model Number :
APD-15
Certification :
CE,ISO, SASO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T
Supply Ability :
10000SETS/YEAR
Delivery Time :
25 DAYS
Packaging Details :
NUDE PACKING,PLYWOOD CASE
Cooling system :
Air-cooled & naturally aspiration
type :
air cooled diesel generator
Engine model :
F4L912TD
Alternator type :
Self-excitation , brushless type
After-sales service provided :
Online support,Free spare parts
Starting :
DC 12V Electronic start
Governer :
Mechanically
Name :
43kva 34kw diesel generators
Product name :
silent air cooled wind kva diesel generator portable
Engine type :
4-cylinder ,4-Stroke
Description

43kva 34kw F4l912td Deutz Diesel Engine Air Cooled Diesel Generator Silent Canopy Genset With Ats

Features :

Generator Supply Scope

1. Engine: Brand-new engine.

2. Alternator: Brand new brushless alternator, single bearing, IP23, H insulation class.

3. Base Frame: Heavy duty steel channel base frame.

4. Radiator: With safety guard.

5. Vibration Damper Vibration damper between Engine/Alternator and base frame

7. Equip Superior quality "VARTA" battery

8. Best quality soundproof Materials to Redue the sound

9. Best quality Power Coating/ Mat Finish

10. Stainless Steel all Screws, Nuts, Bolts and Door Locks & Hinges, Anti-rust.

TECHNICAL DATA:

MODEL APD-43
PRIME POWER (KVA/KW) 43/34
STANDBY POWER(KVA/KW) 47.3/37.4
Rated voltage(V) 400/230
Rated speed(rpm) 1500
Rated frequency(Hz) 50
Power factor 0.8
Ambient temperature(℃) 40
Altitude(m) 1000
Connection type 3 phase 4 wires
Model F4L912TD
Rated Power(kW) 38
No. of cylinders & configuration In-Line 4 cylinders
Method of operation 4-stroke
Speed regulation Mechanical governor
Starting system DC 12V Electronic start
Cooling method Air-cooled & naturally aspiration
Total displacement(L) 2.827
Bore×Stroke(mm) 100*120
100% Load fuel consumption(L/h) ≤ 3
ALTERNATOR MANUFACTURER STAMFORD
Number of Phase 3
Connection Type 3Phase and 4Wires
Number of Bearing 1
Power Factor 0.8
Protection Grade IP23
Terminal 12
Winding/ Pitch 100% Copper 2/3 Pitch
Cooling Fan Cast alloy aluminum
Exciter Type Brushless, Self-Exciting
Insulation Class, Temperature Rise H/H
Telephone Influence Factor( TIF) TIF <50 / THF<2%
Total Harmonic TGH/THC <1.5% at no load / <5% at load
Voltage Regulation, Steady State ≤± 1%
Sustained Short-Circuit Current 300%(3 in): 10s
CONTROL SYSTEM UK DEEP SEA SERIES

43KVA 34KW Canopy Diesel Generator , Electric Start Silent Generator
