Water Cooled 125KVA 100KW Fawde Diesel Generator
Water Cooled 125KVA 100KW Fawde Diesel Generator
Water Cooled 125KVA 100KW Fawde Diesel Generator
Water Cooled 125KVA 100KW Fawde Diesel Generator
Specifications
Brand Name :
ACEPOW
Model Number :
APF-125
Certification :
CE,ISO, SASO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T
Supply Ability :
10000SETS/YEAR
Delivery Time :
25 DAYS
Packaging Details :
NUDE PACKING,PLYWOOD CASE
Engine :
Water-Cooled Engine
Engine 2 :
Battery Switch
Engine 3 :
Draining Oil Pump
Engine brand :
Fawde
Type :
silent diesel generator
Rated power :
100KW/125KVA
Alternator :
Stamford/Leroy Somer/Marathon
Cooling method :
50℃ Radiator, External Water Inlet
Generator type :
Silence Generator Set,Silent(super Silent)or Open Gene
Fuel tank :
Base Fuel Tank
Description

Big Daily Fuel Tank Silent Diesel Generator 125kva 100kw Fawde Ultra Silent Diesel Generator Set

Product description :

1) Brand-new engine,w/start motor.
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
3) Auto control panel with LCD display.
4) Skid-mounted bottom 8 hours fuel tank.
5) Extemal recessed emergency stop button for extra safety.
6) Optional: Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system.

Canopy

* All canopy designed with modular principles

* All metal canopy parts painted by electrostatic polyester power paint

* Soundproof design ensure that the noise level be controlled in small scope

* Convenient to lift and move

* Easy to maintenance and operate

Base Frame

* Base frame including position for forklift and crane

* Integral fuel tank

* Daily fuel tank continuously supply for 8-24 hours

* Fuel tank easy to maintain and clean

* Anti-vibration pads are flexed between engine and alternator.

MODEL APF-125
PRIME POWER (KVA/KW) 125/100
STANDBY POWER(KVA/KW) 138/110
Rated voltage(V) 400/230
Rated speed(rpm) 1500
Rated frequency(Hz) 50
Power factor 0.8
Ambient temperature(ºC) 40
ENGINE MANUFACTURER FAWDE
Model CA6DF2-17D
Rated Power(kW) 110
No. of cylinders & configuration In-Line 4 cylinders
Method of operation 4-stroke
Speed regulation Mechanical governor
Total displacement(L) 3.86
Compression ratio 17.0:1
Bore×Stroke(mm) 102*118
100% Load fuel consumption(L/h) ≤7
ALTERNATOR MANUFACTURER STAMFORD
Number of Phase 3
Connection Type 3Phase and 4Wires
Number of Bearing 1
Power Factor 0.8
Protection Grade IP23
Generating Set Model Length (L) mm Width (W) mm Height (H) mm Net
kg (lb)		 Gross
kg (lb)
APX-125 2250 900 1400 1220 1300
APXS-125 2920 1080 1670 1660 1740
Dry = With Lube Oil Wet = With Lube Oil and Coolant
