25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
25KVA Canopy Diesel Generator
Specifications
Brand Name :
ACEPOW
Model Number :
APW-25
Certification :
CE,ISO, SASO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T
Supply Ability :
10000SETS/YEAR
Delivery Time :
25 DAYS
Packaging Details :
NUDE PACKING,PLYWOOD CASE
Frequency :
50HZ
Speed :
1500RMP
Rated current :
Depend
Rated voltage :
400/230V,220V,220/380V
Output type :
AC Three Phase/ single phase
Type :
Open/silent/mobile
Warranty period :
1000hour working time
Product name :
Diesel Genertor set
Cooling method :
Water cooling or air cooling
Control panel :
digital control system
Description

Denyo Design Canopy Diesel Generator 25kva 20kw Three Phase Single Phase 50hz 60hz Generator Set Pricelist

DESCRIPTION :

1. Power by RICARDO Engine

2. With Stamford / Leroy Somer / Marathon Alternator

Engine

* Heavy duty diesel engine

* Four stroke, water cooled

* 12V and 24V stater and charge alternator

* Cooling radiator and fan

Alternator

* Brushless, single bearing, flexible disc

* Insulation class: H

* Protection class: IP23

Canopy

* All canopy designed with modular principles

* All metal canopy parts painted by electrostatic polyester power paint

* Soundproof design ensure that the noise level be controlled in small scope

* Convenient to lift and move

* Easy to maintenance and operate

Output Ratings
Generating Set Model Prime Standby
APW-25 25kVA/20kW 28kVA/22kW
Generating Set Model Length (L) mm Width (W) mm Height (H) mm Net
kg (lb)		 Gross
kg (lb)
APW-25 1650 750 1150 620 670
APWS-25 2050 850 1150 840 890
Ratings and Performance Data
Engine Brand Ricardo
Engine Model K4100DS
Alternator Brand Stamford
Alternator Model BC184ES / S0L2-M1
Control System Smartgen HGM6120N
Circuit Breaker Type /
Frequency / Phase 50Hz/ Three phase
Engine Speed ( RPM) 1500Rpm
Fuel Tank Capacity (L) 50
Fuel Consumption rate (g/kW.h) 258
Model Type Open / Silent
Standard Package Plywood case/ Plastic
Noise Level@7m (dBA) 70
Generator set Manufacture Acepow
Oil Consummption (L/h) 1.07
Volatage (V) 220/230/240
Silencer Noise Reduction (dBA) 10-20

Lubrication System
Maximum Oil Temp.(°C) 100
Oil capacity(L) 13
Lubricating method Pressure lubrication
Oil pressure (Mpa) 0.2-0.4
Oil pressure at idle speed (Mpa) ≥0.10
Oil consumption rate (g/kW.h) ≤2.04
