CTP 10 Points 12.1 Inch Multi Touch Panel TFT LCD With Transparent Touch Screen For Ticket Dispenser

Capacitive Touch Panel Specifications:

Capacitive Touch Screen:

Capacitive Touch Panel is to use the working current of induction of human body.The operational principle of the projected capacitive touch panel: There are two layers of the ITO layer under the surface of glass. This ITO layer respectively forms the electric field of X axis and Y axis, which can keep balance by crossing the surface of the class. Once the fingers approach the glass surface, the fingers and the electrode X axis or Y axis will form a new electric field, which can make the local capacitance change. Then the controller will determine the location based on capacitance changes.

LCD Specifications:

Introduce:

The LQ121K1LG52 is a 12.1 inch diagonal a-Si TFT-LCD display panel product from Sharp Corporation (hereafter called SHARP), with an integral WLED backlight system, With LED Driver. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Panelook in the following: Antiglare Surface, Wide Viewing Angle, Landscape type, Wide Temperature, White LED Backlight, Lamp life ≥ 50K hours, Wide Aspect Ratio, 180 Reverse , Mass production from Dec. 2010. Based on its features, Panelook recommend that this model be applied to Gaming, Industrial Application etc.

Projected Capacitive touch screen Features:

►Response speed fast, smooth touch.

► Flat panel, more high-end atmosphere, eliminating infrared touch screen surface with a groove edges are not allowed to shortcomings.

►Any point can withstand more than 50 million times touch.

► Operating systems strong compatibility.

► Intelligent automatic calibration, use forinternal / external variety of environments.

► Long life, low maintenance costs.

G+G means the structure of touch panel using Cover Glass + Sensor Glass. The Sensor Glass have

ITO coating so that it can be sensitive.

Advantages of G+G structure:

(1)High transmittance,>83%.

(2)Hard and anti-wear surface.The hardness is 6H.

(3)Excellent corrosion resistance.

(4)Sensitive touch and stable performance.

Why choose us?

1.Our factory is a legal,responsible,capable,experienced factory.

2.We have the largest laminting mechine which can up to 65inch.

3.In stock for fast delivery provide the best after-sales service.

4.We can provide the best design solutions according customer requirements.

5.All of our products have been inspected strictly before delivery.

Customer question

1. How about Sample lead time ?

-------Custom samples 12-18work-days,standard samples 5~10work-days.

2. How about mass production lead time ?

------ 15 days after sample confirmed.

3.Shipping?

------Usually we deliver our goods by DHL,UPS, FedEx etc.

4: Payment term?

------ T/T or Western Union 30% deposit, 70% balance should be paid before shipment.

5: How about the warranty?

------ Warranty 1year.
