75BPM 350ml Plastic Tube Filling And Sealing Machine For Cosmetic Tube 0.5MPa
75BPM 350ml Plastic Tube Filling And Sealing Machine For Cosmetic Tube 0.5MPa
75BPM 350ml Plastic Tube Filling And Sealing Machine For Cosmetic Tube 0.5MPa
75BPM 350ml Plastic Tube Filling And Sealing Machine For Cosmetic Tube 0.5MPa
Specifications
Brand Name :
Fair Machinery
Model Number :
FFD-A
Certification :
CE, ISO, SGS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union. L/C
Supply Ability :
100 pcs per month
Delivery Time :
10-20 days
Packaging Details :
wooden packaged
Material :
304 or 316 Stainless steel
Automatic Grade :
Automatic
Key Selling Points :
fully Automatic, High-accuracy, Easy to Operate
Application :
Beverage, Food
Driven Type :
Pneumatic
Packaging Type :
CANS, Bottles, Stand-up Pouch, Film, Foil, Pouch
Packaging Material :
Paper, plastic, Glass
Function :
sealing, film cutting
Filling Accuracy :
±1%
Warranty :
1 year
Core Components :
PLC, Engine, Motor
Voltage :
380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ
After-sales Service :
video technical support, free spare parts, field installation, commmissioning and training, field maintenance and repair service, online support
Description
Automatic Cosmetic Lotion Gel Jelly Hand Cream Metal Soft Mini Plastic Tube Filling And Sealing Machine
This machine is a high technical equipment which successfully developed and designed by introducing into advanced overseas technology and integrating GMP requirement. It adopts with PLC controller, automatically operating from liquid or high velocity material filling till batch number printing (include manufacture date), it's an ideal equipment for ALU tube, plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, foodstuff, adhesives etc industries.
Technical parameters:
Model FFD-A
Power (KW) 2.2 KW
Speed (BPM) 40-75 B/Min
Filling volume 5-350ml
Filling accuracy ≤±1%
Tube length 50-240
Tube diameter Φ10- Φ50
Tube material Metal tube, ALU tube, Plastic tube, Compound tube
Working pressure 0.5-0.6MPa
Power supply (VAC) 380V 220V 50/60HZ
Dimensions (MM) 2500x1200x2400
Net weight (KG) 1200

Features
1). With both tubes inner wall and external heating devices, ensures each tube tail sealed firmly, with high speed;

2). With mark locating sensor, can always seal the tubes at the same fixed position precisely;

3). Bucket with stirrer, can work with various liquid or cream, paste products;

4). Advanced PLC and touch screen operate system, easy to operate;

5). With graduator, ensures the rotary plate with the 8 (or 10) tubes can turn a precise same angle or circular distance each time;

6). With embossing codes, can make date or batch codes on each tube tail automatically;

7). With shears device, can trim the sealed edge automatically, ensures every tube with uniform and beautiful tail.

8). With high automation, except inset the empty tubes by hand, all the remaining work stages are finished by the machine automatically.

9). Finished tubes can spring into cartons or boxes, no need take them by hand.

FAQ:

F: What is tube filling and sealing machine?

A: Tube filling and sealing machine is used for filling of polyethylene and laminated tubes with gels, creams or other fluids, sealing them with hot air, stamping date and / or batch No. and cutting excess plastic on the tube ending, which arises during the tube sealing.
