120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo
Specifications
Brand Name :
Xidao
Model Number :
XD-DC1000-120KW
Place of Origin :
sichuan
MOQ :
1
Price :
negotiate
Payment Terms :
L/C, T/T
Supply Ability :
5000 per month
Delivery Time :
15-30 work days
Packaging Details :
Wooden case packaging
Product name :
120KW EV Charger
AC input voltage :
380V±15%
Output Voltage and Current :
200～1000V;0～200A
Output Power :
Double gun 120KW
Communication interface :
4G, RS485, CAN, Ethernet (optional)
Efficiency :
≥96%
Protection Level :
IP54/sheet metal shell
Display Mode :
7" Color Touch Screen
Description

Chademo 120KW DC Commercial EV Charger Wifi 4G OCPP1.6 With Payment LCD Display

Product Features

1.connection protection, shutdown protection and human-machine interface operation authority protection.
2. Reduce energy loss, in line with energy saving and emis- sion reduction requirements, saving electricity costs for customers
3. A variety cf control modes to facilitate maintenance and related experiments, a variety of cherging modes to meet the different needs of customers
4.Low input harmonics - reduce pollution to the grid, higher grid adaptability Wide input voltage, wide output voltage range - suitable
for most different input and output voltage situations.
5. Wide operating temperature range-/de operating tempe- rature range to meet most harsh working environments Hol-swappable-suitable for easy use and reduced mainte- nance costs
6. Real-time display of communication, charging operation and battery status through HMI
7. Flexible billing function Multiple billing methods and time-of-day billing to meet customers' diversfied charging needs

Product Parameters

Project Parameter index Remarks
Model

XD-DC1000-120kW-EU
Dimensions 1866.5x715x559mm height*width*depth
AC input voltage 380V±15% Three-phase five-wire system
AC input frequency 45Hz～65Hz
rated power 120kW
The output voltage DC200～1000V(300-1000V constant power)
Output current 0～200A
power factor ≥0.99 Output condition above 50% P0
efficiency ≥96% peak efficiency
Measurement method DC metering Accuracy class 0.5
cooling method forced air cooling
Protection class IP54
Operating temperature -20℃～50℃ Derating work above 50℃, stop working at 70℃
Relative humidity ≤95 % no condensation
Communication Interface 4G, RS485, CAN, Ethernet (optional)
Installation method floor-mounted fixed
Start method Scan code to start

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

Details Images

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

120KW DC charger ccs2 Fast Commercial EV Charger Wifi 4G OCPP1.6 With Payment IK54 Chademo

NOTE:

1- OEM supported.

2- Any requirement please contact us to talk about the details.

3- We will reply you for your inquiry in 24 hours.

4- If you have any questions about the charger, please contact us.

5- The above for reference only, final price decide by the charger KW, please contact us to get the correct quote.
