300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot
300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot
300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot
300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot
Specifications
Certification :
CE, ROHS, ISO9001, Patent
Brand Name :
iStartek
Place of Origin :
Guangdong, China
Supply Ability :
999999 Piece/Pieces per Month
Packaging Details :
Product size: 195mm x 122mm x 26mm Packing size: 267mm x 238mm x 35mm Weight: 250g Packing weight: 481g
MOQ :
2 Pieces
Price :
$1.00-$19.00/PC
Model Number :
MC118 4G Wireless Router
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Delivery Time :
1-7 days
Product Name :
high power 700mhz fiber 4g wifi wireless router
Standards And Protocols :
Wi-Fi 802.11b, Wi-Fi 802.11g, Wi-Fi 802.11n
Wired Transfer Rate :
150 Mbps
2.4G Wi-Fi Transmission Rate :
300 Mbps
Encryption Type :
WPA2-PSK, WPA-PSK, WPA2(AES)-PSK
Products Status :
New
Type :
Wireless
Application :
Home and outdoor
Description

home plastic case multi sim gateway high power 700mhz fiber 192.168.0.1 4g wifi wireless router

MC118 Definition

iStartack MC118 wifi router is made of industry grade pcb board, with overcurrent protection. It has 4 high gain antennas (dual 3G/4G antennas+duel 2.4G antennas), to keep strong signal receving. Watchdog design that can keep the device continuous stable working. Especially, it can support 5-12V power supply, free use device by connecting power bank. MC118 router is perfect for home use.

APPLICATIONS

300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot

SPECIFICATIONS

Device Model MC118 4G Wireless Router
CPU MTK RT7628, MIPS CPU, Basic frequency: 580Mhz
LTE Chipset USE Qualcomm 9X07
RAM 512Mb DDR2
Flash 64Mb SPI Flash
Wireless communication Speed 2.4Ghz 2T2R MIMO max300Mbps
Optional Version
CAT4		 TD5
MDM9607, CAT4
(Aisa, Euro, Au, LA, AF, Middle East, Ocean)		 LTE FDD: B1/B2/B3/B4/B5/B7/B8/B17/B20/B28
TDD-LTE: B38/39/40/41
WCDMA: B1/B2/B5/B8
TDSCDMA: B34/B39
CDMA&EVDO: BC0
GSM: 850/900/1800/1900
TE5
MDM9207, CAT4
(Asia, Africa, Euro, AU)		 LTE FDD: B1/B3/B5/B7/B8/B20
TDD-LTE: B38/39/40/41
WCDMA: B1/B5/B8
GSM: 850/900/1800/1900
ML7820+ XCI_SU FDD-LTE B1/3/5/8
TDD-LTE B34/38/39/40/41
TDS B34/39 +WCDMA B1/8
ML7820+ CeI_SU FDD B1/3/5/8
TDD B38/39/40/41
TDS B34/39
WCDMA B1/8
GSM 900/1800
Optional Version
CAT6		 Coming Soon
Note: Customization of 3G.4G frequencies are available.
Data service
CAT4		 TDD-LTE 3GPP R9 CAT4 DL: 112.5Mbps, UL: 12.5Mbps
FDD-LTE 3GPP R9 CAT4 DL: 150Mbps, UL: 50Mbps
WCDMA DL: 21Mbps, UL: 5.76Mbps
TD-SCDMA DL: 2.8Mbps, UL: 2.2Mbps
EDGE Class12, DL: 236.8kbps, UL:118kbps
GPRS Class10, DL: 85.6kbps, UL: 85.6kbps
GSM CSD:9.6kbps
Transmit power TD-LTE/FDD-LTE: +23 ±2dBm(Power class 3)
TD-SCDMA:24dBm +1dB/-3dB (power class 2)
WCDMA: +24 +1/-3dBm(Power class 2)
GSM B5/8: +33 ±2dBm(Power class 4)
GSM B2/3: +30 ±2dBm(Power class 1)
What New? 1. 4 High gain antennas (dual 3G/4G antennas+duel 2.4G antennas), keep strong signal receiving
2. Inbuilt watch Dog, keep device continuous stable working
3. Industry grade PCB design, with overcurrent protection
4. Support 5-12V power supply, free use device by connecting a power bank
Interface Type micro USB DC IN power port *1(5-12V adaptive)
5.5*2.1mm DC IN port port *1(5-12V adaptive)
RESET button *1
LAN*4 (WAN/LAN0adaptive)10/100Mbpsadaptive
Indicator PWR WiFi SYS LAN3 LAN2 LAN1 WAN/LAN0 4G/3G 30% 60% 100%
Antennas Dual external high gain 4G/3G omnidirectional antenna
Dual external high gain 2.4G omnidirectional antenna
Device Color White
Device Size 19.5*12.2*2.6 (not including antennas)
Power Consumption Typical power consumption <7W
Protocol Standard IEEE 802.11b/g/n
Operating frequency 2.4G
Default gateway 192.168.10.1
Default SSID 4G-CPE-****
Default password 12345678
Working Mode 3G/4G Wireless router mode
Standard router mode
Wireless AP+Wireless client bridging mode
Wireless AP+Client mode
Working Temperature —10℃ to 40℃
storage temperature —40℃ to 70℃
operating humidity 40% to 90% RH No condensation
storage humidity 10% to 95% RH No condensation

ACCESSORIES

Router Power Adapter User Manual

CERTIFICATES

CE RoHS ISO9001 Patent

PICTURES

300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot300Mbps 700mhz Home Gateway Sim 4g LTE Router With Sim Slot

FAQ

Do you provide customer LOGO?
Yes, we can provide customer LOGO on firmware and hardware.
Do you accept PCBA orders only?
Of course, as an OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.
Do you provide firmware support?
Sure thing, unlike other companies which are buying solutions from design company, we have our own
firmware development team to support you in 100%.
Do you.....
Maybe, why don't contact us now! Inquiring us to see if we can, or if we do, to see if we can surprise you!
