300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V
300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V
300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V
300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V
Specifications
Certification :
CE, ROHS, ISO9001, Patent
Brand Name :
iStartek
Place of Origin :
Guangdong, China
Supply Ability :
999999 Piece/Pieces per Month
Packaging Details :
Industry grade pcb board fiber optic 192.168.0.1 300mbps wireless 3g 4g lte wifi modem routerProduct size: 195mm x 122mm x 26mmPacking size: 267mm x 238mm x 35mmWeight: 250gPacking weight: 481g
MOQ :
2 Pieces
Price :
$1-$19.00
Model Number :
MC118 4G Wireless Router
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Delivery Time :
1-7 days
Product name :
fiber optic 192.168.0.1 300mbps wireless 3g 4g lte wifi modem router
CPU :
MTK RT7628, MIPS CPU, Basic frequency:580Mhz
LTE Chipset :
Qualcomm MDM9x07
Power :
9V/12 V 1.0A-2.0A
RAM :
512Mb DDR2
Flash :
64Mb SPI Flash
Wireless communication Speed :
2.4Ghz 2T2R MIMO max300Mbps
Device Size :
19.5*12.2*2.6 (not including antennas)
Power Consumption :
Typical power consumption <7W
Warranty :
1 Year
Description

Industry pcb board fiber optic 300mbps wireless 3g 4g lte wifi modem router

FEATURES

♦ MTK RT7628, MIPS CPU, Basic frequency:580Mhz, powerful performance and work stably;
♦ Support IEEE 802.11b, IEEE 802.11g, IEEE 802.11n wireless network protocol.
♦ LAN*4 (WAN/LAN0 adaptive)10/100Mbps adaptive.
♦ Wireless rate up to 300Mbps.
♦ One key recovery production setting.
♦ Support several encryption mode, such as FDD-LTE, TDD-LTE, TD-SCDMA, WCDMA, EVDO, GSM and so on.

SPECIFICATIONS

Device Model MC118 4G Wireless Router
CPU MTK RT7628, MIPS CPU, Basic frequency: 580Mhz
LTE Chipset USE Qualcomm 9X07
RAM 512Mb DDR2
Flash 64Mb SPI Flash
Wireless communication Speed 2.4Ghz 2T2R MIMO max300Mbps
Optional Version
CAT4		 TD5
MDM9607, CAT4
(Aisa, Euro, Au, LA, AF, Middle East, Ocean)		 LTE FDD: B1/B2/B3/B4/B5/B7/B8/B17/B20/B28
TDD-LTE: B38/39/40/41
WCDMA: B1/B2/B5/B8
TDSCDMA: B34/B39
CDMA&EVDO: BC0
GSM: 850/900/1800/1900
TE5
MDM9207, CAT4
(Asia, Africa, Euro, AU)		 LTE FDD: B1/B3/B5/B7/B8/B20
TDD-LTE: B38/39/40/41
WCDMA: B1/B5/B8
GSM: 850/900/1800/1900
ML7820+ XCI_SU FDD-LTE B1/3/5/8
TDD-LTE B34/38/39/40/41
TDS B34/39 +WCDMA B1/8
ML7820+ CeI_SU FDD B1/3/5/8
TDD B38/39/40/41
TDS B34/39
WCDMA B1/8
GSM 900/1800
Optional Version
CAT6		 Coming Soon
Note: Customization of 3G.4G frequencies are available.
Data service
CAT4		 TDD-LTE 3GPP R9 CAT4 DL: 112.5Mbps, UL: 12.5Mbps
FDD-LTE 3GPP R9 CAT4 DL: 150Mbps, UL: 50Mbps
WCDMA DL: 21Mbps, UL: 5.76Mbps
TD-SCDMA DL: 2.8Mbps, UL: 2.2Mbps
EDGE Class12, DL: 236.8kbps, UL:118kbps
GPRS Class10, DL: 85.6kbps, UL: 85.6kbps
GSM CSD:9.6kbps
Transmit power TD-LTE/FDD-LTE: +23 ±2dBm(Power class 3)
TD-SCDMA:24dBm +1dB/-3dB (power class 2)
WCDMA: +24 +1/-3dBm(Power class 2)
GSM B5/8: +33 ±2dBm(Power class 4)
GSM B2/3: +30 ±2dBm(Power class 1)

ACCESSORIES

Router Power Adapter User Manual

APPLICATIONS

300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V

CERTIFICATES

CE RoHS ISO9001 Patent

PICTURES

300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V300mbp Pcb Board Fiber Optic Port Mapping 4g Lte Wireless Router 9V

FAQ

Do you provide customer LOGO?
Yes, we can provide customer LOGO on firmware and hardware.
Do you accept PCBA orders only?
Of course, as an OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.
Do you provide firmware support?
Sure thing, unlike other companies which are buying solutions from design company, we have our own
firmware development team to support you in 100%.
Do you.....
Maybe, why don't contact us now! Inquiring us to see if we can, or if we do, to see if we can surprise you!
