Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Specifications
Place of Origin :
Guangdong, China
Brand Name :
NANHUA
Model Number :
NHD-8101
Packaging Details :
standard export package
Supply Ability :
1000 Set/Sets per Month
MOQ :
2 sets
Price :
$1,300.00/sets >=2 sets
Certification :
CE
Payment Terms :
L/C, D/A, D/P, T/T
Delivery Time :
15
Model :
124 Spider (348_)
Year :
2016-
Type :
headlight, Headlight
Voltage :
voltage
Car Fitment :
Abarth
Combination :
SDK
Warranty :
12 Months
Electronic :
No
Item Width :
59cm
Material Type :
steel and others
Item Length :
60cm
Item Weight :
30kg
Software Version :
nha
Item Height :
160cm
Item Type :
Mechanical Testers
Description

Excellent NHD-8101 headlight tester with laser alignment function:

NHD-8101 type headlamps detector (hereinafter referred to as the instruments) suitable for checking the automobile, motorcycle, the motor vehicle headlamps on the luminous intensity, light high and volume of offset.
1. Have Chinese liquid crystal display interface, standard RS-232-C communication interface and simulation data output interface, and optional low power consumption mode with batteries work.
2. Rapid decomposition and assembly, and convenient to move.
3. Easy operation, measurement accuracy and other advantages, applicable to vehicle testing station and flow of motor vehicle headlamps lines of testing. Also it is suitable for automobile maintenance, maintenance units of vehicle headlamps light ray position adjustment and detection.
4. Has the auxiliary headlamps Angle correction function (instrument signal automatically adjust the headlamp direction).
Steel NHD-8101 Headlight Tester With Laser Alignment Function 59cm Width
Main parameters:
Luminous intensity
0 ~ 60,000cd (100,000cd)
Headlamps center high50 ~ 130cm

Axis offset
Up1º30′ ~ down2º30′ (up20cm/10m ~ down40cm/10m)
Left2º30′ ~ right2º30′ (left40cm/10m ~ right40cm/10m)
Luminous intensity ±12%
Headlamps center high
±1cm
Detection distance50cm
Power supply
AC220V±10% 50Hz±1Hz or 1 9V battery
Size605mm × 1,600mm× 595mm
Weight30Kg
