Durable Snap In Car Tyre Valve Hardware Alloy Material TR415 / TR414C / TR423

Specifications

Brand Name :

GWA

Model Number :

Tyre valve different models

Place of Origin :

China

MOQ :

3000pcs

Payment Terms :

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability :

1000000pcs each month

Delivery Time :

30 working days

Packaging Details :

Carton box

Model :

Tyre valve models

Color :

Silver

Type :

Tubelss tyre valve

Material :

Alloy

Description

Tire Valve Hardware - Snap-in Tire Valves,TR415,TR413C,TR414C,TR418,TR423,600HP

Tire Valve Hardware - Snap-in Tire Valves

These valves are for passenger car, trailer, light truck, industrial utility, motorcycle, and garden tractor vehicle applications.

DILL P/N	DILL ACP P/N	TR P/N	DESCRIPTION	EFFECTIVE LENGTH	VALVE HOLE SIZE
T-12-R	T-12-WZ	412	65 psi max. cold inflation pressure	0.88″	0.453″
T-13-R	T-13-WZ	413	65 psi max. cold inflation pressure	1.25″	0.453″
T-14-R	T-14-WZ	414	65 psi max. cold inflation pressure	1.50″	0.453″
T-15-R	T-15-WZ	415	65 psi max. cold inflation pressure	1.25″	0.625″
T-18-R	T-18-WZ	418	65 psi max. cold inflation pressure	2.00″	0.453″
T-23-R	T-23-WZ	423	65 psi max. cold inflation pressure	2.50″	0.453″
T-25-R	T-25-WZ	425	65 psi max. cold inflation pressure	2.00″	0.625″
E-600-D	E-600-WZ	600HP	80 psi max. cold inflation pressure	1.27″	0.453″
T-12-S	T-12-WZS	412	Chrome Sleeve TR-412 Valve	0.88″	0.453″
T-13-S	T-13-WZS	413	Chrome Sleeve TR-413 Valve	1.25″	0.453″
T-14-S	T-14-WZS	414	Chrome Sleeve TR-414 Valve	1.50″	0.453″
T-15-S	T-15-WZS	415	Chrome Sleeve TR-415 Valve	1.25″	0.625″
T-18-S	T-18-WZS	418	Chrome Sleeve TR-418 Valve	2.00″	0.453″
T-23-S	T-23-WZS	423	Chrome Sleeve TR-423 Valve	2.50″	0.453″
E-600-S	E-600-WZS	600HP	Chrome Sleeve TR-600HP Valve	1.27″	0.453″
-	801-HP	801HP	80 psi max. cold inflation pressure	1.31″	0.625″

Recommended maximum rim thickness at valve hole for 65 psi inflation pressure snap-in valves is 0.156″. For 80 psi snap-ins, maximum rim thickness is 0.205″.

Tire Valve Hardware - Performance/Specialty Valves

Note: Valve assemblies on this page are pressure rated to 200 psi.

VS-944DW
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
1.13″ effective length

VS-944R
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
1.13″ effective length

VS-902CR
Chrome low profile valve
Sealing valve cap
1.44″ effective length
2 Grommets for 0.453″ and
0.625″ valve hole

TR416
Chrome low profile valve
Sealing valve cap
1.44″ effective length
2 Grommets for 0.453″ and
0.625″ valve hole

VS-911
Designed to fit unusual valve
Hole locations of late model
Toronado and Eldorado
0.453″ Valve hole

VS-902-W
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
1.44″ effective length
Torque 25-45 inch lbs

VS-902-WP
Sealing plated extension
0.453″ valve hole
1.94″ effective length
6541-N sealing valve
Sealing chrome valve cap
Torque 25-45 inch lbs

VS-962C
Ford F-Series Trucks with
inner dual wheels
Sealing metal cap
0.453″ valve hole
Torque 25-45 inch lbs

VS-902K
Ford F-Series Trucks
with outer steel wheels
Sealing metal extension
0.453″ valve hole
1.94″ effective length
Torque 25-45 inch lbs

Tire Valve Hardware - Truck & Bus Valves

Clamp-In Valves

High temperature Ozone resistant grommet standard.
Parts available with various caps and grommets.
Parts may be manufactured at various bend angles as requested.
Bending the valves after installation may cause air loss.

VS-1223WZ

DILL USA	TR P/N	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	LENGTH FROM BEND TO VALVE MOUTH	PACK QUANTITY
VS-500R	500	0.625	2.00″	-	-	-	-
VS-501R	501	0.625	1.50″	-	-	-	-
VS-570R	570	0.625	3.13″	-	-	-	-
VS-571R	571	0.625	3.38″	-	-	-	-
VS-572R	572	0.625	3.75″	-	-	-	-
VS-573R	573	0.625	4.38″	-	-	-	-
VS-574R	574	0.625	4.38″	-	-	-	-
VS-903R	575	0.625	1.13″	-	-	-	-
VS-1223R	-	0.625	-	1.00″	23 degrees	1.00″	-

DILL ACP	TR P/N	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	LENGTH FROM BEND TO VALVE MOUTH	PACK QUANTITY
TR-575	575	0.625″	1.13″	-	-	-	-
VS-500-WZA	500	0.625″	2.00″	-	-	-	-
VS-501-WZA	501	0.625	1.50″	-	-	-	-
VS-570-WZA	570	0.625	3.13″	-	-	-	-
VS-571-WZA	571	0.625	3.38″	-	-	-	-
VS-572-WZA	572	0.625	3.75″	-	-	-	-
VS-573-WZA	573	0.625	4.38″	-	-	-	-
VS-574-WZA	574	0.625	4.38″	-	-	-	-
VS-1223-WZ	-	0.625	-	1.00″	23 degrees	1.00″	-

O-Ring Clamp-In Valves

V3-204

V3-205

DILL P/N	TR P/N	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	LENGTH FROM BEND TO VALVE MOUTH	PACK QUANTITY
V3-201	V3.20.1	9.7mm	1.42″	-	-	-	-
V3-204	V3.20.4	9.7mm	-	0.98″	27 degrees	2.36″	-
V3-205	V3.20.5	9.7mm	-	0.98″	27 degrees	1.57″	-
V3-206	V3.20.6	9.7mm	-	0.98″	27 degrees	3.35″	-
V3-207	V3.20.7	9.7mm	-	0.99″	27 degrees	1.97″	-
VS-542	542	9.7mm	1.47″	-	-	-	-
VS-543	543	9.7mm	2.52″	-	-	-	-
VS-543C	543C	9.7mm	-	0.93″	45 degrees	1.38″	-
VS-543D	543D	9.7mm	-	0.98″	60 degrees	1.38″	-
VS-543E	543E	9.7mm	-	0.98″	75 degrees	1.38″	-
VS-544	544	9.7mm	3.07″	-	-	-	-
VS-544D	544D	9.7mm	-	0.98″	60 degrees	1.94″	-
VS-544E	-	9.7mm	2.52″	-	-	-	-
VS-545B	-	9.7mm	-	1.38″	26 degrees	2.14″	-
VS-545C	-	9.7mm	-	0.98″	36 degrees	2.60″	-
VS-545D	545D	9.7mm	-	0.98″	60 degrees	2.60″	-
VS-545E	545E	9.7mm	-	0.98″	75 degrees	2.60″	-
VS-546B	-	9.7mm	-	0.98″	26 degrees	3.35″	-
VS-546D	546D	9.7mm	-	0.98″	60 degrees	3.35″	-
VS-546E	546E	9.7mm	-	0.98″	75 degrees	3.35″	-
VS-546G	546-36	9.7mm	-	0.98″	36 degrees	0.98″	-
VS-547D	547D	9.7mm	-	0.98″	60 degrees	3.78″	-
VS-551	-	9.7mm	-	0.99″	27 degrees	1.19″	-
VS-1229	-	9.7mm	-	0.98″	27 degrees	2.40″	-

VS-550 Series

Used on many Alcoa wheel applications.
Recommended installation Torque 80-120 inch lbs

VS-553-C

DILL P/N	TR P/N	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	LENGTH FROM BEND TO VALVE MOUTH	PACK QUANTITY
VS-552	552	9.7mm	1.26″	-	-	-	10
VS-553	553	9.7mm	2.31″	-	-	-	10
VS-553-C	553-C	9.7mm	-	0.93″	45 degrees	1.38″	10
VS-553-E	553-E	9.7mm	-	0.98″	75 degrees	1.38″	10
VS-554-D	554-D	9.7mm	-	0.98″	60 degrees	1.94″	10
VS-555-D	555-D	9.7mm	-	0.98″	60 degrees	2.60″	10
VS-555-E	555-E	9.7mm	-	0.98″	75 degrees	2.60″	10

Heavy Truck Tire Valves

VS-902VL

SK-2924

VS-943

DILL P/N	TR #	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	EFFECTIVE LENGTH (FROM BEND TO VALVE MOUTH)	PACK QUANTITY
VS-943	-	0.625″	-	-	21 degrees	1″	-
SK-2924	-	1/8″ NPT	2.04″	-	-	-	-
VS-902VL	-	0.625×0.875″	1.5″	-	-	-	-

VS-879-RW

DILL P/N	TR #	VALVE HOLE	TOTAL EFFECTIVE LENGTH	LENGTH (FROM VALVE SEAT TO THE BEND)	BEND ANGLE	EFFECTIVE LENGTH (FROM BEND TO VALVE MOUTH)	PACK QUANTITY
VS-879-RW	510	0.625″	-	-	90 degrees	5.50″	-
VS-946-RW	509	0.625″	-	-	90 degrees	4.75″	-
VS-949-RW	511	0.625″	-	-	90 degrees	4.25″

Tire Valve Hardware - Motorcycle & Enkei Valves

Note: Click on product images for larger views.

VS-1218 Motorcycle Valve
TR420
O-ring seal
0.327″ valve hole
1.18″ effective length

VS-954 Motorcycle Valve
TR435
Nickel Plated
0.453″ valve hole
1.29″ effective length

VS-934E
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
1.50″ effective length

VS-935E
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
2.08″ effective length

VS-936E
Chrome low profile valve
Sealing valve cap
0.453″ valve hole
1.69″ effective length

Tire Valve Hardware - Valve Cores

Note: Click on product images for larger views.

70-HT
Large Bore
Opening Pressure:
35 psig
Cup Seal Material:
Silicone

70-HV
Large Bore
Opening Pressure:
35 psig
Cup Seal Material:
Viton

100-AA
Opening Pressure:
60 psig
Cup Seal Material:
Nitrile

100-CS
Opening Pressure:
40 psig
Cup Seal Material:
Neoprene

100-FX
Opening Pressure:
130 psig
Cup Seal Material:
Low Temp
Fluorocarbon

100-GL
Opening Pressure:
80 psig
Cup Seal Material:
Low Temp
Fluorocarbon

100-GP
Opening Pressure:
10-50 psig
Cup Seal Material:
Low Temp
Fluorocarbon

100-GS
Opening Pressure:
0-3 psig
Cup Seal Material:
Nitrile

100-HA
Opening Pressure:
80 psig
Cup Seal Material:
Silicone

100-KK
Opening Pressure:
4-15 psig
Cup Seal Material:
Low Temp
Fluorocarbon

100-LG
Opening Pressure:
40 psig
Cup Seal Material:
Neoprene

100-LH
Opening Pressure:
40 psig
Cup Seal Material:
EPDM

100-LP
Opening Pressure:
30 psig
Cup Seal Material:
Hydrin

100-LT
Opening Pressure:
30 psig
Cup Seal Material:
Hydrin

100-MKW
Opening Pressure:
80 psig
Cup Seal Material:
Neoprene

100-SV
Opening Pressure:
80 psig
Cup Seal Material:
Low Temp
Fluorocarbon

100-TP
Opening Pressure:
80 psig
Cup Seal Material:
Silicone

100-VB
Opening Pressure:
30 psig
Cup Seal Material:
Low Temp
Fluorocarbon

302-DL
Opening Pressure:
80 psig
Cup Seal Material:
Neoprene

302-DN
Opening Pressure:
80 psig
Cup Seal Material:
Nitrile

302-DV
Opening Pressure:
80 psig
Cup Seal Material:
Low Temp
Fluorocarbon

402-AH
Opening Pressure:
80 psig
Cup Seal Material:
Silicone

Warning: Do not re-use valve cores in any application.

Valve Cores Application Guide

Dill P/N	Application	Standards	Opening Pressure (psig)	Max. Working Pressure (psig)	Temp. Range (°F)	Cup Seal Mat’l	Comments/Special Instructions
70-HT	Large Bore	TR C2,A-A-52611	35	450	-65 to 250	Silicone	0.13″ pin travel
70-HV	Large Bore	TR C2	35	450	-20 to 250	Low Temp Fluorocarbon	0.13″ pin travel
100-AA	Tank Valve	TR C1,A-A-52611	60	300	-40 to 225	Nitrile	A-A-52611 supersedes ZZ-V-25
100-CS	Refrigeration	OEM	40	500	-40 to 250	Neoprene	0.145″ pin travel; R12, R22, R134a, R407a, R410a; control stop feature
100-FX	OBDII Diagnostic Port	OEM OBD II	130	100	-40 to 250	Low Temp Fluorocarbon	0.07″ pin travel; Gasoline and Flex Fuel applications
100-GL	Fuel Rail	OEM	80	300	-40 to 250	Low Temp Fluorocarbon	Flex Fuel – methanol/gasoline
100-GP	Gas Pump	Pump Mfg.	10-50	300	-40 to 250	Low Temp Fluorocarbon	Gasoline and Flex Fuel
100-GS	Low Pressure Drop	Compression Tester	0-3	300	-40 to 225	Nitrile	200 psig flow pressure
100-HA	Tire Valve	TR C1	80	300	-65 to 250	Silicone	Car, truck, and bus tire valve
100-KK	Tank Valve	None	4-15	300	-40 to 250	Low Temp Fluorocarbon	Oil and Fuel resistant
100-LG	Refrigeration	SAE J639	40	500	-20 to 250	Neoprene	0.145″ pin travel; R12, R22, R134a, R407a, R410a; control stop feature
100-LH	Refrigeration	SAE J639	40	500	-40 to 250	EPDM	0.145″ pin travel; R134a
100-LP	Propane/Fuel	CGA 600	30	500	-40 to 250	Hydrin	0.145″ pin travel
100-LT	Propane	UL147A,CGA 600	30	500	-20 to 200	Hydrin	0.145″ pin travel
100-MKW	Refrigeration	ARI 720	80	700	-40 to 250	Neoprene	R12, R22, R134a, R407a, R410a; control stop feature
100-SV	Fuel Rail	OEM	80	300	-20 to 250	Low Temp Fluorocarbon	Oil and Gasoline resistant
100-TP	TPMS	TR C1	80	300	-65 to 250	Silicone	Car
100-VB	Mapp Gas	UL147A,CGA 600	30	400	-20 to 250	Low Temp Fluorocarbon	0.145″ pin travel
302-DL	Refrigeration	ARI 720	80	2000	-20 to 200	Neoprene	High pressure refrigeration
302-DN	Strut Valve	AN-809	80	3000	-65 to 225	Nitrile	Oil resistant
302-DV	Oxygen	Portable Cylinders	80	2000	-30 to 250	Low Temp Fluorocarbon	Not cleaned for oxygen service
402-AH	Aircraft	TR C4,I Product tags axle seal leak , vulcanizing rubber to steel , pressure tyre Send your message to this supplier Message* Email* Phone or WhatsApp* Name Company Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Send Now Submission successful! Durable Snap In Car Tyre Valve Hardware Alloy Material TR415 / TR414C / TR423 Ask Latest Price Product Detail Brand Name : GWA Model Number : Tyre valve different models Place of Origin : China MOQ : 3000pcs Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 1000000pcs each month Contact Supplier Globe Auto Industry Co.,Limited Active Member 7 Years zhejiang, ningbo Since 1999 Business Type : Manufacturer Main Products : Car Wheel Spacers, ATV Wheel Spacers, Coil Spacer Lift Kit Total Annual : 5000000-10000000 Certification Level : Active Member Discover similar products Stable Snap In Tire Schrader Valve , Standard Car Valve Stem 11.5 Mm Rim Holes Contact Now Automatic Vacuum Car Tire Valve 1.4 X 0.75 Inch Dimension For ATV Motorcycle Contact Now Black Rubber Car Tyre Valve Caps 5 Cm Effective Length Easy Installation Contact Now Zinc Alloy Tubeless Car Tyre Valve Silver MS525 5.2 X 0.5 Cm With Dust Caps Contact Now Snap In Car Tyre Valve Maximum 65 PSI , 0.453 Inch Rubber Valve Stems TR413 Contact Now High Precision Tire Valve Core Stem Replacement With 6 Mm Thread Diameter Contact Now Silver Universal 135 Degree Metal Tyre Valve Stem Adapter Easy Maintenance Contact Now Auto / Truck / Motorcycle Tire Valve Stem Kit With 7.5 Mm Threaded Hole Dia Contact Now Durable Car Tyre Valve Extension Gold , Valve Stem Extenders 45 / 135 Degree Contact Now Copper 1.5 Inch 90 Degree Valve Stem Extension Adapter For Motorcycles Contact Now View More Find Similar Products By Category: Supplier Homepage Products Car Tyre Valve MachineU China Products Tools & Hardware Valve Valves Contact Supplier Message* Email* Phone or WhatsApp* Name Company Submit Requirement Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Submitted successfully! Your request message has been successfully sent to the supplier. Please keep in touch and they will contact you as soon as possible. OK China Hot Products: A \| B \| C \| D \| E \| F \| G \| H \| I \| J \| K \| L \| M \| N \| O \| P \| Q \| R \| S \| T \| U \| V \| W \| X \| Y \| Z \| 0~9 Copyright © 2009-2025 Machineu.com. All rights reserved. Copyright © 2009-2025 Machineu.com. All rights reserved.

Tire Valve Hardware - Snap-in Tire Valves,TR415,TR413C,TR414C,TR418,TR423,600HP

Tire Valve Hardware - Snap-in Tire Valves

Tire Valve Hardware - Performance/Specialty Valves

Tire Valve Hardware - Truck & Bus Valves

Clamp-In Valves

O-Ring Clamp-In Valves

VS-550 Series

Heavy Truck Tire Valves

Tire Valve Hardware - Motorcycle & Enkei Valves

Tire Valve Hardware - Valve Cores

Valve Cores Application Guide

axle seal leak

vulcanizing rubber to steel

pressure tyre

Durable Snap In Car Tyre Valve Hardware Alloy Material TR415 / TR414C / TR423

Globe Auto Industry Co.,Limited

Stable Snap In Tire Schrader Valve , Standard Car Valve Stem 11.5 Mm Rim Holes

Automatic Vacuum Car Tire Valve 1.4 X 0.75 Inch Dimension For ATV Motorcycle

Black Rubber Car Tyre Valve Caps 5 Cm Effective Length Easy Installation

Zinc Alloy Tubeless Car Tyre Valve Silver MS525 5.2 X 0.5 Cm With Dust Caps

Snap In Car Tyre Valve Maximum 65 PSI , 0.453 Inch Rubber Valve Stems TR413

High Precision Tire Valve Core Stem Replacement With 6 Mm Thread Diameter

Silver Universal 135 Degree Metal Tyre Valve Stem Adapter Easy Maintenance

Auto / Truck / Motorcycle Tire Valve Stem Kit With 7.5 Mm Threaded Hole Dia

Durable Car Tyre Valve Extension Gold , Valve Stem Extenders 45 / 135 Degree

Copper 1.5 Inch 90 Degree Valve Stem Extension Adapter For Motorcycles

Find Similar Products By Category:
