Specifications
Brand Name :
Carav/OEM
Model Number :
CCS-100M*I
Certification :
CE, FC, RoHS
Place of Origin :
China
MOQ :
2 pcs
Price :
$28.00 - $35.00
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000pcs per month
Delivery Time :
5-8 days
Type :
SM Card, Card Reader
Interface :
Usb, USB 2.0
Card Slots :
All in 1 / Multi in 1
Installation :
External
Dimensions :
100mm(L)x34mm(W)x30mm(H)
Weight :
85g
Read card :
1/2/3tracks
Card :
Magnetic card,IC card
Operating system :
Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux
Description
Supply Ability
Supply Ability
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
The packing details of chip card writer and reader:
Box +carton
100pcs per carton
Carton Size:56*28*44cm
Port
shenzhen,HK
Lead Time:
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 6 To be negotiated
CCS-100MI Smart Card Reader Writer,Magnetic Card Reader & Chip Card Reader
Type Smart Card Reader Writer,Magnetic Card Reader & Chip Card Reader
Communications USB2.0,USB-OTG(Android 3.1 above)
Maximum power consumption 100 mW
Temperature

Commercial-:-20°∼ 60 °C

Industrial-:-20°∼ 60 °C

Humidity 90% non- condensing
Anti-static interference 15KV
Magnetic interference resistance 19Oersted
Vibration resistance Amplitude 0.35mm,Frequency 10-55Hz,Three axis directions sweep vibration
Insulation Resistance

Hot and humid circumstances(40°,95%)Insulation resistance

should not be less than 5MΩ

Dimensions 100mm(L) ×34mm(W) × 30mm(H)
Weight 85g
Magnetic card
Selectable tracks yes
Read card 1/2/3tracks
Swipe Double direction
Swipe speed 3 ~ 60 inches per second
Head life Approx 500,000 passes
Parity and LRC checking Built-in, audible and LED good read and error indicator
Cards supported ISO 7811,AMMVA,CADMV
Head life Approx 200,000 passes
Communications USB
operating system Win7, Win 2008 ,Vista, Win 2003, Win 2000, XP, Linux
IC Card
Cards supported

AT24C01A/24C02/24C04/24C08/24C16/AT24C64,SLE4432/4442,

SLE4418/4428,

ISSI 24C01A/16,ISO7816-(1-4) (T=1, T=0)

1/2/3 tracks Smart Card Reader Writer 100mW Usb Magnetic Card Reader

Feasures:

1.Thin,light and beauful,practical

2.Post,no additional power supply

3.via USB interface to communicate with the computer, support android platform

4.can read a variety of memory cards and supports T = 0, T = 1 protocol CPU card

5.supports a variety of systems: Windows XP, Windows visa, Windows7, Linux, etc.

6.variety SDK sample program

7.Logo,color,shape customize avaliable

1/2/3 tracks Smart Card Reader Writer 100mW Usb Magnetic Card Reader
1/2/3 tracks Smart Card Reader Writer 100mW Usb Magnetic Card Reader
1/2/3 tracks Smart Card Reader Writer 100mW Usb Magnetic Card Reader

1.Q:Are you a manufacturer?
Geesung: Yes,we are a manufacturer.

2.Q: What warranty do you offer?
Geesung: Each product with 1 year warranty,expect the human damage and force majeure factor .

Beyond the guarantee period machine ,we will provide maintenance service and technical support.

3.Q:Are you still worry about compatibility of PC with your software?
Geesung: Before you make the order, you could test your software if compatible with

our hardware, you could send your software to us or you could Teamviewer.

4.Q:Do you still have lots of complains of after-sales?
Geesung: With our experience, it is better for you to have a hardware engineer, Once meet problems,you check and solve it at the first time ,avoid causing other trouble ,even irreversible damage. Also you could return to us ,in order to save the shipping cost ,you’d better collection 3pcs of damaged one,then send back to us together. Shipping cost you pay yourside, we pay ourside.


5.Q:Are you buy for personal use, retail or wholesale?
Geesung: If you regularly buy POS products, to protect your clients and also save cost for you.

We suggest you could buy extral 2-3 units as reserves for unexpected needs.


6.Q: What about minimum order quantity?

Geesung: We have no limit for MOQ, so you can even buy only 1 piece.


7.Q: Are you factory, can you do OEM/ODM?
Geesung: Yes, we are factory, we produce touch monitors, all in one pc,

and we can customize as your requirements.


8.Q:How can I pay for the order?
Geesung: Our payment terms :T/T ,Western Union ,Paypal,Trade assurance Order

We are 13 years of Alibaba golden supplier for the all in one POS system ,Trade assurance limit :$79000


9.Q:How do I know that you have sent the products out?
Geesung: Once the products are sent out, a tracking number will be provided so that you can check where your goods at all times


10.Q:What kind of inspection you can provide ?
Geesung: Each POS machine will ageing test 48 hours ,to guarantee all POS machine are in the perfect condition before shipment .we also accept the inspection by the third part you appointed.
