Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel
Specifications
Brand Name :
Sanyinghe
Model Number :
As your requirements
Certification :
ISO
Place of Origin :
Zhuzhou-China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
10000Pcs/Month
Delivery Time :
5-25 days
Packaging Details :
1 PCS/ PVC Packing, 10 PCS PVC Packing
Product name :
apex screw point tap
Unit :
PCS
Specifications :
M1-M20
Processing technology :
full grinding
Standard :
Metric
Finish :
Titanium Plated Gold
Description

Quality Machine Titanium Coated Spiral Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel

Product Description:

Tip taps/pointed taps/fluted taps: mainly used for thread cutting operations of various through-hole materials.

The tip tap has the same straight groove as the general straight groove tap, but there is a specially designed helical groove at the front end of the cutting part, so as to rotate and push the cutting to be discharged from the bottom of the hole.

Specifications:

Material High Speed Steel
Packing 1ps/ Plastic Box
Suitable Stainless Steel/Die Steel
Applicable tools CNC/tapping machine/drilling and milling machine
Performance Bottom chip removal, through hole
Advantage Strong heat dissipation, good through-hole effect

Note:

These sizes we have in stock, and the other sizes,we can produce for you based on your requirements. Any need, please free comments.

Specification Tooth spacing Thread Length(mm) Shank diameter(mm) Total length(mm) Head Punch diameter(mm)
M1*0.25 0.25 5.5 3 32 pointed head 0.75
M1.2*0.25 0.25 5.5 3 32 pointed head 0.95
M1.4*0.3 0.3 8 3 36 pointed head 1.1
M1.6*0.35 0.35 8 3 36 pointed head 1.25
M1.7*0.35 0.35 8 3 36 pointed head 1.35
M1.8*0.35 0.35 8 3 36 pointed head 1.45
M2*0.4 0.4 9.5 3 42 pointed head 1.6
M2.5*0.45 0.45 9.5 3 44 pointed head 2
M3*0.5 0.5 11 4 46 pointed head 2.5
M4*0.7 0.7 13 5 52 pointed head 3.3
M5*0.8 0.8 16 5.5 60 pointed head 4.2
M6*1 1.0 19 6 62 pointed head 5
M8*1.25 1.25 22 6.2 70 flat head 6.8
M10*1.5 1.5 24 7 75 flat head 8.5
M12*1.75 1.75 29 8.5 82 flat head 10.3
M14*2 2.0 30 10.5 88 flat head 12
M16*2 2.0 32 12.5 95 flat head 14
M18*2.5 2.5 37 14 100 flat head 15.5
M20*2.5 2.5 37 15 105 flat head 17.5

Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel

Titanium Coated Spiral Point Tap Tip Tap M3 M4 M5 M6 M8 Stainless Steel

FAQ

1. Who are we?

Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.

2. How can we guarantee quality?

We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.

3. What can you buy from us?

We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.

4. How is the packing?

All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.

5. What is your terms of payment?

Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
