Specifications
Brand Name :
Sanyinghe
Model Number :
D4/6/8/10/12/16/20mm
Certification :
ISO
Place of Origin :
Zhuzhou,China
MOQ :
5PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
3000pcs/month
Delivery Time :
7 days
Packaging Details :
1PCS In 1 Plastic Box, and Servel Boxes In 1 Carton.
Material :
Tungsten Carbide
Usage :
Copper, Cast Iron, Carbon Steel, Mould Steel etc.
Application :
Metal Machining
OEM :
Yes
HRC :
45/55/60/65 HRC
Description

2 Flute Corner Radius End Mill HRC65 8mm Solid Carbide Cutting Tools Milling Cutter For Stainless Steel

PRODUCT DESCRIPTION

Product Name

 Carbide End Mills
Material Carbide
Coating AITiN
Type Corner radius carbide end mills
Processing Objects Carbon Steel
Features End mill for iron, steel, stainless steel, aluminum

1.End mills application: cutting of stainless steel, cast iron, aluminum, nickel, steel

2.End mills: 2 flutes, 3 flutes, 4 flutes

3.Types: solid carbide end mills, corner radius end mils, ball nose end mills

4.End mill length: 50mm, 85mm, 100mm, 150mm, 200mm

5.End mill hardness:45HRC 55HRC6 5HRC

Item Grade

HRC45

(YG10X )

HRC55

(YL10.2 & WF25)

HRC60

(Germany K44 &K40)

HRC65

(Sandvik H10F)
Details

Grain size 0.7um

Co10%
Flexural strength

3320N/mm2

Grain size 0.6um
Co10%

Flexural strength 4000N/mm2

Grain size 0.5um

Co12%
Flexural strength
4300N/mm2

Grain size 0.5um
Co10%

Flexural strength 4300N/mm2

Corner Radius End Mill
Specification-R0.2
Flute
1
D1R0.2*3*D4*50L
4
2
D1.5R0.2*4.5*D4*50L
4
3
D2R0.2*6*D4*50L
4
4
D2.5R0.2*7.5*D4*50L
4
5
D3R0.2*9*D4*50L
4
6
D4R0.2*12*D4*50L
4
7
D6R0.2*15*D6*50L
4
8
D8R0.2*20*D8*60L
4
Corner Radius End Mill
Specification-R0.5
Flute
1
D2R0.5*6*D4*50L
4
2
D2.5R0.5*7.5*D4*50L
4
3
D3R0.5*9*D4*50L
4
4
D3.5R0.5*10.5*D4*50L
4
5
D4R0.5*12*D4*50L
4
6
D4R0.5*14*D4*75L
4
7
D4R0.5*16*D4*100L
4
8
D5R0.5*12.5*D5*50L
4
9
D6R0.5*15*D6*50L
4
10
D6R0.5*20*D6*75L
4
11
D6R0.5*25*D6*100L
4
12
D8R0.5*20*D8*60L
4
13
D8R0.5*25*D8*75L
4
14
D8R0.5*30*D8*100L
4
15
D10R0.5*25*D10*75L
4
16
D10R0.5*30*D10*100L
4
17
D12R0.5*30*D12*75L
4
18
D12R0.5*35*D12*100L
4
Corner Radius End Mill
Specification-R1
Flute
1
D3R1*9*D4*50L
4
2
D3R1*9*D3*50L
4
3
D4R1*12*D4*50L
4
4
D4R1*14*D4*75L
4
5
D4R1*16*D4*100L
4
6
D5R1*12.5*D5*50L
4
7
D5R1*15*D5*75L
4
8
D5R1*12.5*D6*50L
4
9
D6R1*15*D6*50L
4
10
D6R1*20*D6*75L
4
11
D6R1*25*D6*100L
4
12
D8R1*20*D8*60L
4
13
D8R1*25*D8*75L
4
14
D8R1*30*D8*100L
4
15
D10R1*25*D10*75L
4
16
D10R1*30*D10*100L
4
17
D12R1*30*D12*75L
4
19
D12R1*35*D12*100L
4
Corner Radius End Mill
Specification-R2
Flute
1
D8R2*20*D8*60L
4
2
D10R2*25*D10*75L
4
3
D12R2*30*D12*75L
4

2 Flute High Speed Carbide End Mills HRC65 8mm Milling Cutter For Stainless Steel2 Flute High Speed Carbide End Mills HRC65 8mm Milling Cutter For Stainless Steel2 Flute High Speed Carbide End Mills HRC65 8mm Milling Cutter For Stainless Steel

FAQ

1. Who are we?

Sanyinghe is professional cutting tool supplier founded in 2014. Sanyinghe has a excellent teams in designing and manufacturing. Welcome to contact with us, we can meet all your requirement.

2. How can we guarantee quality?

We own optimized design concept advanced testing equipment and strict production process, so we can guarantee quality steadily.

3. What can you buy from us?

We can provide you tungsten carbide end mills, tungsten carbide indexable inserts, cermet (metal ceramic) indexable inserts, tungsten carbide or HSS drills, and milling cutter head, milling cutter arbor, cnc tool holder,and so on.

4. How is the packing?

All the packing will meet the strict export packing requirement, we surely understand how important the beautiful and firm packaging to the goods.

5. What is your terms of payment?

Generally by T/T, Paypal, Western Union. We support EXW, FOB, FCA, CFR, CIF, and DDP Terms.
