YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
Specifications
Brand Name :
OED/OEM is available
Model Number :
Carbide wear ring
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
Small qty of amples are available.
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000kgs per month
Delivery Time :
Standard products in one week, special tools in 45 days
Packaging Details :
plastic box/box + Cartons
Material :
Tungsten carbide
Applicatin :
Wear rings
ISO Grade :
None
Length :
36
width :
32
Height :
11
TRS :
3200
Hardness :
HRA 88
Density :
13.8
Description

YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings​

No-Magnetic Wear rings
Outer diameter 36 +0.05
Inner 32 -0.005
Height 11 +0.2

Carbide Material YN11

Nickel 11%

Density 13.8g/cm3

HRA 88

Corrosion resistance carbide wear rings with polished inner diameter.

YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect RingsYN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings

Grade recommended:

Wear part grades Grade ISO Grade Co Density Hardness T.R.S. Grain size
OK05UF K05 6.00 14.90 93.20 3000 Ultra Fine
OK10F K10-K20 6.00 14.90 92.00 2000 Middle/Fine
OK30M K30 8.00 14.80 91.50 2200 Fine
OK40F K40 10.00 14.45 91.90 3400 Middle/Fine
OK50M K50 12.00 14.25 90.00 3500 Fine
OG30M G10 8.00 14.70 91.00 2100 Middle
OG60M G20 11.00 14.40 89.00 2400 Middle
OG70M G30 15.00 14.20 86.70 2800 Middle
OG80M G40 20.00 13.65 85.00 3000 Middle
OG90M G50 25.00 13.20 84.20 3200 Middle

Corrosion resistance grades:

Corrosion resistant grades Grade Ni Density Hardness Hardness T.R.S. Grain size
HRA HV30
ON10 5.50 14.80 90.90 1,480 ＞1450 Middle
ON20 6.00 14.80 90.80 1,460 ＞1600 Middle
ON30 7.50 14.65 90.30 1,410 ＞1800 Middle
ON40 9.00 14.55 89.20 1,310 ＞2150 Middle
ON50 10.00 14.40 89.00 1,300 ＞2300 Middle
ON60 11.00 14.20 88.50 1,250 ＞2450 Middle
ON70 15.00 13.15 84.10 950 ＞2650 Middle

YN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect RingsYN11 No-Magnetic Wear Rings Finished Polished Carbide Precision Protect Rings
