High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
Specifications
Brand Name :
Skywell
Model Number :
U24T03000-45
Certification :
SGS
Place of Origin :
China
MOQ :
100㎡
Price :
USD6/㎡
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000㎡ per month
Delivery Time :
5-8 days
Packaging Details :
Polyester bag and foam rolling inside,Paper carton out of packing size 121cm*42cm*40cm
Carbon fiber Type :
24Ton And T700
FAW :
30g/㎡
RC :
45%
Thickness :
0.05mm
Total weight :
55g/㎡
Tensile Strength :
4900MPA
Strength Modulus :
240GPA
Density :
1.82
Resin System :
#4177
Carbon fiber :
T700 / TR50S
Scrim :
No
Description

High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack

1. What is the feature of carbon fiber ?

Carbon Fiber's Specisal Features and Characterizing Performances

  • Light in Weight and Strong (Mechanical Performances)
  • Excellent Dimensional Stability and Heat Resistance (Thermal Characteristics)
  • Highly Electric Conductive and Excellent EMI Shielding Propaerty
  • Magnificant X-ray Permeability


2. How to get Pan type carbon fiber ?

Carbon Fibers are manufactured by production processes as illustrated below. Manufacturers produce the fibers under different processing conditions to get assortments of products qualities.


High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack

3. To be suit for different manufacturer progress.

High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
4. Application:

High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack


5. Resin system :

There are 8 different resin systems , Here you can find one that suits you . Please go to download our spreadsheet of products.



High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack

Resin No.Resin TypeCuring Temperature ℃Features & applications
#450Epoxy130High flex ,impact resistant,Fishing rob,Golf,rolling tube
#469Epoxy130General industry,sporting equipment, bicycle frame,bicycle rims,Racket,hockey stick
#477Epoxy130The better improved type than #469,Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,better transparency,self-adhesive, sporting products like bike,racket,hockey,golf etc
#4177Epoxy135Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,half of transparency, higher self-adhesive
#4619Epoxy135Not suitable for products asked by nice transparency apperance,And lower resin loss rate, general sporting products
#502ABEpoxy130Specially Designed for impact resistant, the #502A Most used in non-transparency products , And #502B used in transparency products ,like safe helmet
#3016TGEpoxy160impact resistant,most suitable for products that needs high temperature resistant,like road bicycle rims ,braking system
#3017TGEpoxy180Be suitable for products that needs high temperature resistant,flame retardant, TG point for 180℃ to 190℃
#8005Epoxy180Aircraft,PC products,Flame retardant, high standard under Germany DIN5510-2 ,And United State UL94V0.





6. Carbon Fiber Specification :

TypeTicknessFAW (g/㎡)RC (%)Total weight (g/㎡)Tensile strength (MPA)Tensile Modulus (GPA)
U24T03000-450.05055451514900240

High Performance Prepreg Carbon Fiber Fabric U Directional For Building Crack
