MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands
MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands
MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands
MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands
Specifications
Brand Name :
Skywell
Model Number :
U36T01750-36
Certification :
SGS
Place of Origin :
China
MOQ :
100㎡
Price :
USD10/㎡
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000㎡ per month
Delivery Time :
5-8 days
Packaging Details :
Polyester bag and foam rolling inside,Paper carton out of packing size 121cm*42cm*40cm
FAW :
175g/㎡
RC :
36%
Thickness :
0.181mm
Total weight :
273g/㎡
Tensile Strength :
4410MPA
Strength Modulus :
345GPA
Resin System :
#4177
Carbon fiber :
MS40,M35J
Scrim :
No
Description

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

1. What is the feature of carbon fiber ?

Carbon Fiber's Specisal Features and Characterizing Performances

1>. Light in Weight and Strong (Mechanical Performances)

2>. Excellent Dimensional Stability and Heat Resistance (Thermal Characteristics)

3>. Highly Electric Conductive and Excellent EMI Shielding Propaerty

4>. Magnificant X-ray Permeability

2. How to get Pan type carbon fiber ?

Carbon Fibers are manufactured by production processes as illustrated below. Manufacturers produce the fibers under different processing conditions to get assortments of products qualities.

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

3. To be suit for different manufacturer progress.

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

4. Application:

  • Sporting goods : Golf shafts , Fishing Rods, Bicycle parts , Etc
  • Industrial Applications : Composite Robot Hands and Other LCD / Semiconductor Application ,Composite roller ,Automotive parts ,Electronic Application, Etc.

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

5. Resin system :

Resin No. Resin Type Curing Temperature ℃ Features & applications
#450 Epoxy 130 High flex ,impact resistant,Fishing rob,Golf,rolling tube
#469 Epoxy 130 General industry,sporting equipment, bicycle frame,bicycle rims,Racket,hockey stick
#477 Epoxy 130 The better improved type than #469,Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,better transparency,self-adhesive, sporting products like bike,racket,hockey,golf etc
#4177 Epoxy 135 Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,half of transparency, higher self-adhesive
#4619 Epoxy 135 Not suitable for products asked by nice transparency apperance,And lower resin loss rate, general sporting products
#502AB Epoxy 130 Specially Designed for impact resistant, the #502A Most used in non-transparency products , And #502B used in transparency products ,like safe helmet
#3016TG Epoxy 160 impact resistant,most suitable for products that needs high temperature resistant,like road bicycle rims ,braking system
#3017TG Epoxy 180 Be suitable for products that needs high temperature resistant,flame retardant, TG point for 180℃ to 190℃
#8005 Epoxy 180 Aircraft,PC products,Flame retardant, high standard under Germany DIN5510-2 ,And United State UL94V0.

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

6. Carbon Fiber Specification :

Type Tickness FAW (g/㎡) RC (%) Total weight (g/㎡) Tensile strength (MPA) Tensile Modulus (GPA)
U36T01750-36 0.181 175 36 273 4410 345

7. Packing and Storage.

Skywell Carbon prepreg packing and storage 　 　 　 　
Standard length Unidirectional prepreg:100 m 　 　 　 　
Woven prepreg :50 or 100m 　 　 　 　
　 The prepreg is rolled around on paper tube with a silicon -coated separation paper
Packing data And the roll is packed in a sealed polyethylene bag to prevent moisture absorption
　 Diameter of paper tube for unidirectional prepreg :300mm of inner diameter 　
　 Diameter of paper tube for unidirectional prepreg :300mm of inner diameter 　 　 　
　 Storage temperature 130℃ curing grade 180℃ curing grade
　 .-18℃ or less 6 months 6months 　 　
Storage life 5℃ or less 3 months 2months 　 　
　 20℃ or less 1.5 months 14days 　 　
　 The 180℃ curing type is shipped by refrigerated container(-18℃ or less) , 　
SHIPMENT The 130℃ curing type is shipped on regular trucks unless else requested 　
