New 2021 Automatic Corrugated Box Carton Manufacturing Machinery

Function and characteristic:

1, Roller type front feeding structure,rounds,multipoint suction feeding,high friction,high speed,paper feeding smoothly and accurate.

2, Frequency conversion of suction can adjust the wind volume,and the wind pressure can be adjusted by the size of the paperboard,increase the thin board and the bend board convey stability and accurately.

3, The machine gear are 40 cr forging, high frequency quenching treatment, grinding;Using spray type automatic lubrication, greatly improve the operation precision and service life.

4, Machine transmission parts (shaft, gear joint) are adopted free key connection , the connection eliminate clearance. It is suitable for long-term high speed with high torque.

5, Up creasing roller package polyurethane ,Don't damage the cardboard

6, Single roller double blade slotter , carton height adjust adopt PLC and digital electric , touch screen control .

7, Slotting phase adjustment adopt PLC touch screen ,downtime and operation all can be adjusted.

8, Slotting knife holder and careasing roller lateral movement adopts synchronous electric adjustment. PLC touch screen adjustment, direct input the carton size, automatic adjustment.

9, line pressing space and blade shaft space adopt self-locking structure adjustment

10, All the slotting knife holder lateral movement have collision protection deceive ( electrical model )

11, Slotting knife width is 7mm. alloy material, after heat treatment, grinding, tooth slotted knife ,double-piece model cutting edge knife, knife edge sharp, high precision

12, Using "slot revolution" patent technology, improve the slotting precision, no burr, don't pick Angle, effect similar to die cutting.
