Smart Card Plasitc Card Laminating Machine YLL-16A4S PLC Contorlled With 3 Hot Openings And 3 Cooling Openings

Plastic Card Laminator/Smart Card Pressing Machine/Card Laminating Machine YLL-16A4S

1. Introduction of Smart Card Plasitc Card Laminating Machine YLL-16A4S PLC Contorlled With 3 Hot Openings And 3 Cooling Openings

Plastic Card Laminator YLL-16A4S is designed to laminate the bonded PVC sheet assembly into the thicker PVC sheets to be punched. It has one tower with 3 hot openings and 3 cooling openings. It is controlled by PLC which can ensure reliable and precise lamination effect.

2. Features of Smart Card Plasitc Card Laminating Machine YLL-16A4S PLC Contorlled With 3 Hot Openings And 3 Cooling Openings

• It is controlled by PLC to ensure reliable performance. It can laminate various cards including RFID cards Inlay.
• It has the best performance/price ratio, which is very suitable for middle or small card factory.
• The big size cooling parallel loop is specially designed to ensure better cooling effect.

3. Technical Parameter of Smart Card Plasitc Card Laminating Machine YLL-16A4S PLC Contorlled With 3 Hot Openings And 3 Cooling Openings

1). PVC sheet layout: 2×5 for 16A4 model

2). Laminating template size: 230×315mm suitable for A4 PVC sheet lamination

3). Daylight number/distance: 1 tower, 3 hot daylights, 3 cool daylights, 40mm

4). Pressure control precision: +/-1Mpa

5). Work pressure: 0-16Mpa (adjustable).

6). Temperature control precision: +/- 2℃

7). Heating temperature: ≤200 ℃

8). Power: 7.5 KW (Maximum)

9). Power supply: AC380V 50/60HZ 3 phase 4 wires

10). Dimension: around L800×W550×H1200mm

11). Gross weight: Around 500 kg.

12). Speed: 1000 cards per hour.

4. Package of Smart Card Plasitc Card Laminating Machine YLL-16A4S PLC Contorlled With 3 Hot Openings And 3 Cooling Openings

Plastic Card Laminator YLL-16A4S is also named as Smart Card Pressing Machine or Card Laminating Machine YLL-16A4S.
