Mirror Finish PVC Card Lamination Steel Plate YSP-G 0.8mm A3 Size Plastic Card Press Plate

1. Introduction of Mirror Finish PVC Card Lamination Steel Plate YSP-G 0.8mm A3 Size Plastic Card Press Plate

They are applied as the consumables in plastic card lamination. It can well ensure perfect plastic card surface finish after lamination. Our plates are being widely used by many card factories in both China and foreign countries worldwide.

It is also called high glossy lamination plate, ultra glossy lamination plate, lamination steel plate for card laminator, glossy/mirror laminating plate, card finish lamination plate, card production material

Card steel plate has the advantage of good conducting of heat,resisting pressure,high quality mirror. By our steel plates you can produce the international standard card.The more than 10 years of experience of marketing and marketing operation make us choose the best quality steel plates for all our widely card making customers.

2. Key features of Mirror Finish PVC Card Lamination Steel Plate YSP-G 0.8mm A3 Size Plastic Card Press Plate

1). The two sides are covered with protection foils (blue thin films) to ensure good protection on both surfaces. There is no glue left after the foil is removed before the plate is used at the first time.

2). Two sides are made glossy or matte in the same quality.

3). There are no scratches, dents, stripes shadows and dust on plate surfaces.

4). The edges are smooth and deburred with the round curved corners.

5). After lamination, the plates are not sticking to the laminated plastic sheets.

3. Technical Parameter of Mirror Finish PVC Card Lamination Steel Plate YSP-G 0.8mm A3 Size Plastic Card Press Plate

Plate size(L×W): A4, A3 or custom-made size

Plate thickness: 0.6mm, 0.8mm (Thickness tolerance: ±0.05mm)

Dimension tolerance: ±1mm for length and width.

Plate flatness level: maximum 1 mm.m

Surface roughness: Glossy plate (Ra＜0.03μm)

Glossy plate surface glossiness: over 800 GU at 20° (both sides)

Surface hardness: HRC26±2

Thermal transmission: 0.04cal/℃.cm.sec at 20℃

Packaging box: solid plywood carton with soft cushion protection inside.

4. Application of Mirror Finish PVC Card Lamination Steel Plate YSP-G 0.8mm A3 Size Plastic Card Press Plate

The glossy/mirror finish card lamination steel plate is also known or named as mirror finish plastic card laminating plate, high glossy card press steel plate or card laminator’s steel plate.
