108V 325Ah Electric Car Battery IP66 Protection Level ,Fast Charging ,Rohs
108V 325Ah Electric Car Battery IP66 Protection Level ,Fast Charging ,Rohs
Specifications
Brand Name :
Soundon
Model Number :
SD-108-325
Certification :
CE, MSDS, ROSH , UN38.3
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Supply Ability :
500 units / week
Delivery Time :
30 working days after payment
Packaging Details :
1PC / wooden package
Voltage&capacity :
108V 325Ah
Battery cell :
7688190-3.6 V12.5Ah
Battery cell material :
Li polymer battery
Battery pack case :
IP66 protection level
Battery module :
3.6V62.5Ah
Application :
Electric Van car ,electric bus ,solar energy sysetem
Description

108V Lithium Polymer Battery Pack For EV bus , E Truck With Slow And Fast Charging

Electric Vehicle Battery pack Models List we already produced :


MODEL
Voltage(V)
Capacity
(Ah)		 Battery case size Weight
(KG)		 Application
Length(mm) Width(mm) High(mm)
EV-6050 60 50 550 260 260 ≤55 Tourist electric car
EV-6060 60 60 650 340 185 ≤50 Tourist electric car
EV-60100 60 100 560 384 310 ≤90 Fork lift
EV-64400 64 400 1# case: 896 386 300 ≤200 Sanitation truck
2# case: 896 386 300 ≤190
EV-7260 72 60 645 332 200 ≤50 Tourist electric car
EV-72100 72 100 660 340 340 ≤100 EV car
EV-72200 72 200 960 420 360 ≤206 EV car
EV-72250 72 250 800 600 255 ≤207 EV car

Advantage :

Specialist in battery cells Lamination technology with good consistency

Good discharge performance ,battery pack high discharge current can reach 5C

High energy density of battery cell up to 180Wh/Kg and high capacity

Small in volume and light in weight,battery cells less than 270g

High IP level >66

Accredited with ROHS, without toxic waste

Wide operating temperature range ,can stand the higher Tep than 45 degree ,and lower to -20degree

Customization and global after-sales service

Parameter :

voltage/Capacity 108V/325Ah
Voltage Working Range 90V---126V
Total energy 35.1 KWh
Configuration 26P 30S

Charge Current 150A (Fast charging)
60A (Slow charging)
Max Instantaneous Current :325A 10S
Continuous Current :230A 10min

Discharge Current 162.5A
Max Instantaneous Current 500A 10S
Continuous Current 300A 10min


Working Temp. Range Discharge: -20℃~45℃
Charge: -10℃~45℃
Storage Temperature -20～45℃
Relative Humidity 5%~95%
Resistance ≥20MΩ
Protection Level IP66
Cooling Method :Natural cooling
