Four Floors 4 Post 4 Cars Parking Lift

Work Principle

This system is designed with 4 floors to park 4 cars. There are 3 full closed pallets with slopping entrance edges for cars driving in. When parking, all pallets fall down to the ground, the car will park into the top floor first, then top car lift up to position; the second car parks into the middle pallet and lift up to position again; then the third car parks into the bottom pallet and lift up to position; the forth car parks into the ground finally. When retrieving, reverse the steps; Only one by one parking or retrieving; 4 cars will belong to 1 owner or 1 operator. It is mostly used for storage of car sales center.

It is also only 3 floors with 2 full closed pallets to park 3 cars;

Characteristics

• It saves the land area and takes full use of the space area.
• It can be designed with shared columns for more sets to raise the parking numbers of cars.
• Hydraulic cylinder lift with high safety and green environment protection.
• Pallets are full closed design to avoid leakage.
• Designed with guide rail structure to guarantee low noise and steady operation.

Adapted places

Open places for more cars parking, suitable for car sales center for storage.

Advantages

• Hydraulic cylinder fixed stroke control, never over-going, never accident; Motor type easy accident when sensors wrong;
• Double faster speed than motor chain type; Quick parking and retrieving in rush hours.
• Best safety guarantee, sensors, photocells, for all possible detection; Patent safety frame last protection on each pallet;
• Saving electricity without consumption of power when falling.
• Easy maintenance, saving much maintenance cost;
• Low noise, almost silence during operation;
• Full galvanized treatment and most patents design for long-life guarantee.
• No. 1 Sales and biggest parking factory in China with best advanced equipments for quality guarantee.

Technical Parameters
