For Volkswagen Tavendor 9.35-inch touch specific electronic rearview mirror recorder for special vehicles
Description:
Electronic rearview mirror is an indirect field of view device that obtains a specified field of view through a system composed of a camera and a monitor. It includes high-definition cameras, digital visual processing systems, security systems, LCD displays and other electronic devices, and is a new type of rearview mirror that can replace traditional optical rearview mirrors.
Unlike traditional mechanical rearview mirrors, electronic rearview mirrors reflect the rear image on the LCD screen installed inside the car through high-definition cameras installed outside the car, thus achieving the purpose of observing traffic conditions behind. Its advantages include eliminating blind spots, reducing weather interference, and minimizing wind resistance
Product Features Introduction
1. 9.35-inch IPS screen + capacitive 5-point touch.
2. High-definition dual 1080p streaming media driving record.
3. Low-light night vision, dedicated to special cars.
4. Time-lapse video + low-light night vision.
5. Pedestrian monitoring.
6. Parking monitoring.
7. The high-definition rear road can support up to 20 meters, which is suitable for installation of any model.
8. Support, Simplified Chinese, Traditional Chinese, English.
Product detailed parameters
project | parameter | |||
Master control | AC5401B | |||
SDRAM/DDR | DDR2 64MB | |||
Front camera | AHD1080p(1920X1080)@30fps F2.0/ H.FOV110°/ V.FOV60°/ D.FOV150°+F9 | |||
Rear camera | AHD1080p(1920X1080)@30fps F2.0/ H.FOV90°/ V.FOV60°/ D.FOV140°/0.1Lux | |||
MIC | Single microphone with echo and noise cancellation | |||
loudspeaker | Built-in 4Ω/2W | |||
G_sensor | It supports automatic recording of collision and dormant parking detection | |||
TF memory card holder | It is used to store dash cam video, and supports 32GB Class10TF card | |||
power supply | With over-voltage protection, over-current protection, low-voltage protection, | |||
Operating current | ≤1.0A@5V | |||
Standby current | ≤2-3mA | |||
Supply voltage | B+:+12V,ACC:+12V,GND | |||
Operating temperature | -20℃ ~ +70℃ |
Suitable vehicle models
2024 | 330TSI Elite Tour Crowd Enjoyment |
330TSI Luxury Cruiser Enjoyment Edition | |
330TSI Luxury Jiajing Shared Edition (7-seater) | |
380TSI four-wheel drive R-Line touring popular item |
Field of view of electronic rearview mirror
The field of view of traditional physical rearview mirrors is 300%
and a larger field of view can enhance driving safety
Resolve rear seat obstruction
1080P high-definition dual recording before and after, recording the beautiful scenery of the journey
The newly upgraded multi touch screen enables touch control operations for recording start, stop, playback, and other functions, making it more efficient and convenient
One second one shot parking record
In the parked state, the device goes into deep sleep mode and records every second, allowing for the recording of the truth even in the event of an accident!
Safe power management, over-current and over-voltage protection
Simultaneous display of front and rear recording screens
