Smart PKE Push Button Start Remote Start Engine Start System

Preface

This is new smart car alarm system with remote start,push start,passwords key pad and other more practical features and functions.please read this manual before using or installing our product!specially for some important points as below:

1. In driving,don't press start button at will in case of sudden engine off,incurs dangerous situations.
2. If your car has window closer module,don’t leave children inside the car alone.
3. Please change default passwords of touch key pad promptly after installation.
4. Please don't put smart key and mobile together,mobile signal will take interference to smart key normal working.
5. Under the service mode,you can press mute button to disable auto induction function,if need,you also can enable auto induction function by pressing unlock button.
6. Must press the footbrake when push start,don’t need to press footbrake when push stop car engine.
7. If you want to stay inside the car for long time,please disable auto induction function to save smart key battery power by pressing mute button.
8. Auto induction function will be closed automatically if your car stay in a place for more than 3days,but it will recover by pressing remote unlock button.
9. System only recognize one smart key to save battery power of the other one,if you want to enable the other smart key,only press any button of remote manually.

Main fuction

1.Remote engine start
2.Automatic lock/unlock when leaving/closing
3.Electric/Pneumatic lock optional
4.LED indicating
5.Central lock automation
6.One button to start the engine for driving
7.Connect with GPS tracking system ( with GPS hardware together)

Technology Parameter

Working Voltage:12+/-3V
Static Current:<15mA
Shock Sensor Current<1mA
Direction Light 5A,siren 1A
PKE working frequency:125KHZ
Remote Working Frequency:433.92mhz
Output current:ACC/ON/START 30A
Remote voltage:3V
Remote static current<10mA
Battery Type:CR2032
Remote Frequency:433.92mhz
