Horizontal Packaging Carton Folding Machine Semi - Automatic With Pneumatic Locking
Horizontal Packaging Carton Folding Machine Semi - Automatic With Pneumatic Locking
Specifications
Place of Origin :
HeBei Province,China
Brand Name :
XINTIAN
Certification :
CE,ISO9001
Model Number :
XT-L
MOQ :
1set
Price :
$10000-$40000
Packaging Details :
pallet
Delivery Time :
30-90days
Payment Terms :
T/T or L/C
Supply Ability :
30SET/MONTH
Feeding mode :
Chain feeding
Function :
pneumatic locking
Automation :
Semi-Automatic
Roller :
Ink roller and printing pressing roller
Material :
rigid chrome
Surface :
grinded
Precision :
high precision
Speed :
High speed
Description

Horizontal Packaging Carton Folding Machine Semi - Automatic With Pneumatic Locking

Functions and Features:

1. Chain feeding model can ensure that the bent board paper be smoothly sent due to the elastic pressing

plate at the front of feeding system.

2. Motorized detachment and combination; pneumatic locking and loosening of printing units; automatic ink

distribution and pneumatic brake separation orientation.

3. Printing and slotting phase is adjusted by planetary-gear electric phase, shown by digit.

4. Whole machine uses the gear pumping automatic lubrication.

5. Ink roller and printing pressing roller are connected by cross slide to ensure steady transmission.

6. All axles and rollers are plated with rigid chrome and grinded surface.

7. The whole machine adopts the electric parts from CHINT and DELIXI; Whole machine bearing is from the

Harbine Bearing Group.

8. Option of printing slitting and creasing or printing slotting.

Main Technical Parameter

SERIAL

WYAZS NAME

UNIT

WYAZS

2500×2800

1

Inboard width

Mm

3200

2

Max.coverage size

Mm

2500×3100

3

Min.coverage size

Mm

600×500

4

Max.printing area

Mm2

2450×2800

5

Thickness of printing plate

Mm

6

6

Max.speed

Pieces/min

50

7

Power of main motor

Kw

11

8

Size for whole machine

Mm

6000×4200×2500

9

weight

T

15

Horizontal Packaging Carton Folding Machine Semi - Automatic With Pneumatic Locking

Horizontal Packaging Carton Folding Machine Semi - Automatic With Pneumatic Locking
