Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Manual Feeding Corrugated Box Making Machine Electric Phase Printer 380V
Specifications
Brand Name :
Xintian
Model Number :
XT-L
Certification :
CE ISO9001:2000
Place of Origin :
Hebei
MOQ :
1 set
Price :
Negociated
Payment Terms :
TT，L/C
Supply Ability :
2 sets per month
Delivery Time :
30-90 days
Packaging Details :
pallet
Dimensions(L*W*H): :
9500x4500x2200mm
Usage: :
Paper Printer
Voltage: :
380V
Weight: :
20000KG
Description

Manual Feeding Corrugated Box Making Machine Electric Phase Printer​

Function and Characteristics:

●Whole machine axle,roller with rigid chrome and grinded surface;
●Whole machine electric parts was used the international famous brand
●Whole machine bearing was used the Harbine Bearing Group.
●Photoelectric counting,pre-setting order quantity,plan produce.

●Chain feeding model ,Gravure registering is convenient and correct with a clutch between the worktable and unit;
●Motorized detachment and combination, pneumatic locking and loosening of printing units.
●Printing and Slotting phase was adjustment the planetary gear structure 360° electric phase,show with digit;
●Whole machine was used the gear pump automatic lubrication;
●Ink roller and printing pressure roller was connected by cross slide to ensure a stable running.

Note: Die cutter unit can be added if necessary.

Main Technical parameter:

SERIAL WYAZS NAME UNIT WYAZS
1030×1900
(Φ360)		 1450 × 1900/2300/2700
( Φ480 )		 1700×2300/2700
( Φ560 )		 2450 × 2200/2800
( Φ800 )
1 Inboard width size 2200 2200 2600 3000 2600 3000 2600 3200
2 Max.coverage size mm 1080×2000 1500×
2100		 1500×
2500		 1500×
2900		 1750×
2500		 1750×
2900		 2500 ×
2500		 2500×3
100
3 Min finish size mm 260×610 380×
640		 380×
640		 380 ×
640		 450×
720		 450×
720		 500×
600		 500×
600
4 Max.prinling size mm 1030 × 1900 1450×
1900		 1450×
2300		 1450
×2700		 1700×
2300		 1700×
2700		 2450×
2200		 2450 ×
2800
5 Thickness of printing plate mm 6 7.2 7.2 6 6
6 Complete machine baffle thickness mm 50 36 36 50 50
7 Max.speed mm 80 60 60 50 50
8 Topping precision Pieces/min ±0.5 ±0.5 ±0.5 ±0.5 ±0.5
9 Slotting precision mm ±1.5 ±1.5 ±1.5 ±1.5 ±1.5
10 Max.slolting depth mm 250 300 400 600 600
11 Min.slotting interval mm

205×60

×205×60

260×60

×260×60

280×80×

280×80

280×80

×280×80

280×80×

280×80
