Specifications
Brand Name :
Xintian
Model Number :
XT-L
Certification :
CE ISO9001:2000
Place of Origin :
Hebei
MOQ :
1 set
Price :
Negociated
Payment Terms :
TT，L/C
Supply Ability :
2 sets per month
Delivery Time :
30-90 days
Packaging Details :
pallet
Dimensions(L*W*H): :
9500x4500x2200mm
Usage: :
Paper Printer
Voltage: :
380V
Weight: :
20000KG
Description

Semi Automatic Corrugated Box Making Machine 4 Color Carton Flexo Printer

Function and Characteristics:

●Chain feeding model ,Gravure registering is convenient and correct with a clutch between the worktable and unit;
●Motorized detachment and combination, pneumatic locking and loosening of printing units.
●Printing and Slotting phase was adjustment the planetary gear structure 360° electric phase,show with digit;
●Whole machine was used the gear pump automatic lubrication;
●Ink roller and printing pressure roller was connected by cross slide to ensure a stable running.
●Whole machine axle,roller with rigid chrome and grinded surface;
●Whole machine electric parts was used the international famous brand
●Whole machine bearing was used the Harbine Bearing Group.
●Photoelectric counting,pre-setting order quantity,plan produce.

Note: Die cutter unit can be added if necessary.

Main Technical parameter:

SERIAL WYAZS NAME UNIT WYAZS
1030×1900
(Φ360)		 1450 × 1900/2300/2700
( Φ480 )		 1700×2300/2700
( Φ560 )		 2450 × 2200/2800
( Φ800 )
1 Inboard width size 2200 2200 2600 3000 2600 3000 2600 3200
2 Max.coverage size mm 1080×2000 1500×
2100		 1500×
2500		 1500×
2900		 1750×
2500		 1750×
2900		 2500 ×
2500		 2500×3
100
3 Min finish size mm 260×610 380×
640		 380×
640		 380 ×
640		 450×
720		 450×
720		 500×
600		 500×
600
4 Max.prinling size mm 1030 × 1900 1450×
1900		 1450×
2300		 1450
×2700		 1700×
2300		 1700×
2700		 2450×
2200		 2450 ×
2800
5 Thickness of printing plate mm 6 7.2 7.2 6 6
6 Complete machine baffle thickness mm 50 36 36 50 50
7 Max.speed mm 80 60 60 50 50
8 Topping precision Pieces/min ±0.5 ±0.5 ±0.5 ±0.5 ±0.5
9 Slotting precision mm ±1.5 ±1.5 ±1.5 ±1.5 ±1.5
10 Max.slolting depth mm 250 300 400 600 600
11 Min.slotting interval mm 205×60×205×60 260×60×260×60 280×80×280×80 280×80×280×80 280×80×280×80
