Corrugated Cardboard Making Machine Price / Single Color Flexo Printing Machine

Functions and Features:

• Whole machine electric parts are domestic famous brand with good and steady quality

• Tempering is used to decrease metal internal force in complete machine baffles and key parts, and these parts are made by high-precision processing center and grinded by numeric-control grinder.

• All the transmission axles and rollers are made by high-quality steel, and processed by tempering and dynamic balance, plated with rigid chrome and grinded surface

• All the transmission gears are made by the 45# alloy steel, and are grinded after heat-treatment, which maintains high topping precision

• The whole machine adopts spray lubrication, equipped with double oil pipe balance system.

• Optional equipments: presetting adjustment function, feeding, printing, slotting, all featuring automatic zero setting and memory reposition

• Whole machine working interval adjustment, self-lock worm wheel and worm device, fast and convenient

• Vacuum adsorption, kick or lead edge feeding to customers’ request

Option: Ceramic anilox roller and stacker Machine

Main technical parameter

Function of Feeding Department:
● Electrically controlled the connecting and separated for the even/ unit with alarm to ensure the operator safety during its proceeding.
● The left and right baffle,kick feeding,back baffle was adopted electric adjustment;
● Brush and the top suction device at the inlet which can clear away the impurity from the paper face to improve the printing quality;
● Mainframe was controlled by the frequency conversion ,start-up and running steady,which can save the power about the 30%;
● Infrared photoelectricity counter can presetting the order paper quantity;
● One lock function for whole machine ,which can avoid the damaged the machine with error operation (Main motor start running ,every unit will be lock automatic);
● Pressure model elasticity feeding rubber roller,which can not to damaged the strength for corrugated cardboard;
● Option: outside baffle add the flap function,which made the cardboard orientation more exact,avoid to waste.
Option:kick feeding paper or lead edge feeding paper.

Function of Slotting Department:
●Slotting phases was adopted the planetary gear structure, the electric digit 360 adjustnent,show the dgt(stop, running can adjustment);
●Slotting tool rest pressure wheel horizontal move by electric mechanic joint adjustment;
●The height of box size was adjustment synchronous;
●Pressure interval was used the free-spanner self-lock worm wheel and worm device adjustment and fix;
●The elastic tangential scraper structure could cut off three and five layer cardboard without any adjustment.
●Slotting knife was choice with the high quality alloy steel,which made the rigidity and tenacity was best when heat treatment, it can suitable long-term used.
●It could be equipped with portable punching die holder.
●Option: Computer double shaft slotting adjustment.

Function of Die Cutting Department:

●The die cutter phase is controlled by computer and electric digit.
●The die cutting scraper could be adjusted horizontally with manual control ranging from 10mm.
●The glue roller cuts the trimming mechanism and the cushion could be used for many times and save the use cost to a great deal.
●The cushion roller mechanical, horizontal and facility from + 30mm to -30mm could raise the service life of The cushion of the die-cutting.
●Used the die cutting equalizer, providing wire-speed compensation, be ensure the carton forming same size after repair the rubber.
Option: Contain slotter circle blade.
