3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven
3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven
3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven
3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven
Specifications
Brand Name :
Hh
Model Number :
2800mm
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
negotiated
Payment Terms :
T/T, L/C
Supply Ability :
10 sets every month
Delivery Time :
15-30 days
Packaging Details :
plastic
name :
High Speed Fully Automatic Carton Folder Gluer Machine
warranty :
one year
Voltage :
380v/50hz 220v/60hz
Driven type :
electric , pneumatic
max.size :
2800*1200mm
Min.size :
170*420mm
Feeding way :
Continuously Feeding
Glue type :
Water-base Cold Water
function :
Carton Folder Gluer Machine
speed :
0-100pcs/min
Core Components :
PLC, Gearbox, Gear
Dimension(L*W*H) :
12000*2000*1500mm
color :
yello, blue, white or customized
weight :
6500KG
Description

3 Layer 5 Layer Fully Automatic Carton Folder Gluer Machine
Automatic folder gluer machine mainly consists of three parts: feeding part, folding gluing part and stacking counting part, full machine frame made by good quality steel welded .
It adopts PLC programming control, touch screen operation and frequency conversion to adjust speed. The average speed about 150sheets/min, with high speed, saves power and labor

Main specification

team
value
Brand Name
Hh
Condition
New
Warranty
1 Year
After-sales Service Provided
Online support

Key Selling Points
Easy to Operate
Max size (L+W)*2
2800mm
Dimension(L*W*H)
3.8x2x1.5m
Speed
60m/min
Machine weight
1250kg

3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven

Feeding part
Belt type lead edge with vacuum suction feeding system is more better to feed bend board
Good quality electromagnetic clutch and brake system, feeding part can be controlled separately, easy operation.
Scorer wheel is adjustable, it suit to cardboard thickness 2-8mm
It can do second scorer, so correct bad creased board.
Folding & gluing part
Simple structure, glue amount can be adjustable, easy clean
It adopts stainless steel gluing wheel, gluing even, no fault save glue amount.
Automatically gluing, recycle glue, never stop, don’t need add glue by hand, save time and power.
Imported wearable rubber belt convey board, automatically folding.
Equipped with board correction and scorer correction device.
Counting & Stacking part
Stacking and counting are simple and reliable
Digital control, easy operation and reliable. Non-stop enter data, automatically counting and output accurately.
With correction function, correct deviation
Counting and output by pneumatic control, fast and accurately

Our company speciaized in carton machinery for many years in China. Our main products are: high speed automatic flute laminator/ semi-automatic flute laminator/ high speed single facer machine/ corrugated cardboard making line and so on. Our quality is high and price is low, hope we could build a long term business relations. Dongguang Haohan Carton Machinery Co., Ltd. is located in the south of Beijing and north of Jinan, so we have convenient land and water facilities. We are a professional enterprise with a large scale to produce carton machinery and printing machinery. Our company has 80 workers including 10 engineering and technical staff members with senior titles. Our company has capability of product design and perfect quality guarantee system. With perfect technology, complete machine, high specialization degree, rich manufacturing experience, strong technical force, advanced overhauling measures and integrated managing system, our company is like an up-and-coming youngster in the carton printing machinery industry in China. Part of the printing machines made by our company are exported to Southeast Asia, Western Asia, the Middle East and South America.3 Layer 5 Layer Carton Folder Gluer Machine Fully Automatic Pneumatic Driven
